Page 636 - ISCAR(MILLINGCATALOG 38_2021)

BT-HYDRO HD SS LSCWS A 0.003 A 58-60 HRc

BT MAS-403 Heavy Duty, Short CRKS THID LB DCONWS BTED BD 25,000 RPM
ADJRGA

G2.5
Hydraulic Chucks With

BT Form ADB Shanks
U<1.0 gmm
LPR
Designation
BD
LPR
LB
SS
BT40 HYDRO 12X58 HD
M8X1
12.00
10.00
46.0
M16
1.23
32.00
0
BT40 HYDRO 16X72.5 HD 40.0 DCONWS BTED 42.00 58.00 31.0 ADJRGA LSCWS THID CRKS CDI (1) kg
38.00
0
40.0
51.0
72.50
M8X1
49.25
8.00
45.5
16.00
M16
1.30
BT40 HYDRO 20X72.5 HD 40.0 20.00 38.00 49.25 72.50 45.5 8.00 51.0 M8X1 M16 0 1.40
BT50 HYDRO 20X83.5 HD 50.0 20.00 38.00 49.25 83.50 45.5 8.00 51.0 M8X1 M24 0 4.10
BT50 HYDRO 32X90 HD 50.0 32.00 58.50 72.00 90.00 52.0 9.00 61.0 M8X1 M24 0 4.60
(1) 1 - Hole for data chip, 0 - Without hole for data chip
Spare Parts
Designation
BT40 HYDRO 12X58 HD ALLEN KEY SW5X100*
BT40 HYDRO 16X72.5 HD ALLEN KEY SW5X100*
BT40 HYDRO 20X72.5 HD ALLEN KEY SW5X100*
BT50 HYDRO 20X83.5 HD ALLEN KEY SW5X100*
BT50 HYDRO 32X90 HD ALLEN KEY SW6X100*
* Optional, should be ordered separately
SS LSCWS A 0.003 A 58-60 HRc
BT-FC-HYDRO ADJRGA
Hydraulic Chucks with MAS-BT G2.5
Face Contact Form AD Shanks DCONWS BTED BD BD_2 18,000RPM
U<1.0 gmm
CRKS
THID LBX LB
LPR
Designation SS DCONWS LPR BTED BD BD_2 LBX LB ADJRGA LSCWS THID CRKS CDI (1) kg
BT30 FC HYDRO 6X60 30 6.00 60.00 23.00 26.00 - 38.0 33.00 10.00 37.0 M5 M12 0 0.50
BT30 FC HYDRO 8X64 30 8.00 64.00 25.00 28.00 45.00 42.0 29.00 6.00 37.0 M6 M12 0 0.60
BT30 FC HYDRO 10X64 30 10.00 64.00 27.00 30.00 - 42.0 37.00 10.00 42.0 M8x1 M12 0 0.50
BT30 FC HYDRO 12X72 30 12.00 72.00 29.00 32.00 - 50.0 43.00 10.00 50.0 M10x1 M12 0 0.60
BT30 FC HYDRO 14X70 30 14.00 70.00 30.00 34.00 - 48.0 33.00 10.00 48.0 M8x1 M12 0 0.70
BT30 FC HYDRO 16X90 30 16.00 90.00 34.00 38.00 - 68.0 52.00 10.00 52.0 M10x1 M12 0 0.90
BT30 FC HYDRO 18X90 30 18.00 90.00 36.00 40.00 - 68.0 52.00 10.00 52.0 M10x1 M12 0 0.90
BT30 FC HYDRO 20X90 30 20.00 90.00 38.00 42.00 42.00 68.0 - 10.00 52.0 M10x1 M12 0 0.90
• Chucking forces will be reduced by 25% if reduction sleeves are used • Reduction sleeves are available for 12, and 20 mm bore diameters (ordered separately) •
Clamping wrench (wrench HYDRO HEX 4) and test bar should be ordered separately (1) 1 - Hole for data chip, 0 - Without hole for data chip

Spare Parts
Designation
BT-FC-HYDRO HYDRO CLAMP SCREW M8X14
LPR A 0.005 A AT3 Taper 58-60 HRc
BT-EM (Short) SS LB
Short DIN6359 / DIN 1835 Form
B Weldon Endmill Holders with BT
MAS-403 AD Tapered Shanks BD
DCONWS
CRKS
Designation SS DCONWS LPR LB BD CRKS CDI (1) kg
BT40 EM 10X 45 40 10.00 45.00 18.0 35.00 M16 0 1.05 SR M10X12 DIN1835-B
BT40 EM 12X 45 40 12.00 45.00 18.0 42.00 M16 0 1.08 SR M12X16 DIN1835-B
BT40 EM 14X 45 40 14.00 45.00 18.0 44.00 M16 0 1.06 SR M12X16 DIN1835-B
BT40 EM 16X 45 40 16.00 45.00 18.0 48.00 M16 0 1.16 SR M14X16 DIN1835-B
BT40 EM 20X 45 40 20.00 45.00 18.0 52.00 M16 0 1.13 SR M16X10.3 EM SHORT
BT40 EM 25X 45 40 25.00 45.00 - 63.00 M16 0 1.12 SR M18X2X10 EM SHORT
• B is the designation for coolant through flange.
(1) 1 - Hole for data chip, 0 - Without hole for data chip

712-713
