Page 330 - ISCAR(TURNING-CATALOG-42-2022)

GROOVE-TURN THDR/L-IQ 10.00 CDX (1) 25.0 25.0 WF CW CDX WB OAL G1/8” H B WB 20.40 HBH HBL
HF
External Holders for Wide
HBH
Grooving Inserts
HBL

Left-hand shown
OAL
HF
B
CW
H
WF
Designation
8.0
9.20
30.0
170.00
25.0
20.00
THDR/L 2525-10T20-IQ
THDR/L 3232-10T20-IQ
32.0
10.00
170.00
20.00
8.0
32.0
30.0
32.0
9.20
27.40
THDR/L 2525-12T20-IQ
THDR/L 3232-12T20-IQ
32.0
32.0
20.00
32.0
8.0
30.0
11.00
26.50
12.00
170.00
25.0
8.0
25.0
30.0
THDR/L 2525-14T20-IQ
18.50
170.00
13.00
20.00
14.00
25.0
30.0
170.00
13.00
25.50
8.0
32.0
14.00
THDR/L 3232-14T20-IQ 12.00 20.00 25.0 25.0 25.0 170.00 11.00 19.50 8.0 30.0
20.00
32.0
32.0
THDR/L 3232-16T40-IQ 16.00 40.00 32.0 32.0 32.0 170.00 14.80 24.60 8.0 48.0
THDR/L 4040-16T50-IQ 16.00 50.00 40.0 40.0 40.0 180.00 14.80 32.60 - -
THDR 3232-18T40-IQ 18.00 40.00 32.0 32.0 32.0 170.00 16.50 23.80 8.0 48.0
THDR 4040-18T50-IQ 18.00 50.00 40.0 40.0 40.0 180.00 16.50 31.80 - -
THDR/L 3232-20T40-IQ 20.00 40.00 32.0 32.0 32.0 170.00 18.00 23.00 8.0 48.0
THDR/L 4040-20T50-IQ 20.00 50.00 40.0 40.0 40.0 180.00 18.00 31.00 - -
• For grooving only
(1) Cutting depth maximum
For inserts, see pages: TIGER-IQ (329)

Spare Parts
Designation
THDR/L 2525-10T20-IQ PIN 5.5 INJ SR M6-26392 BLD T15/S7 SW6-T
THDR/L 3232-10T20-IQ PIN 5.5 INJ SR M6-26392 BLD T15/S7 SW6-T
THDR/L 2525-12T20-IQ PIN 5.5 INJ SR M6-26392 BLD T15/S7 SW6-T
THDR/L 3232-12T20-IQ PIN 5.5 INJ SR M6-26392 BLD T15/S7 SW6-T
THDR/L 2525-14T20-IQ PIN 5.5 INJ SR M6-26392 BLD T15/S7 SW6-T
THDR/L 3232-14T20-IQ PIN 5.5 INJ SR M6-26392 BLD T15/S7 SW6-T
THDR/L 3232-16T40-IQ PIN 6.5 INJ 7000944 SR M8-26393 BLD T20/S7 SW6-T
THDR/L 4040-16T50-IQ PIN 6.5 INJ 7000944 SR M8-26393 BLD T20/S7 SW6-T
THDR 3232-18T40-IQ PIN 6.5 INJ 7000944 SR M8-26393 BLD T20/S7 SW6-T
THDR 4040-18T50-IQ PIN 6.5 INJ 7000944 SR M8-26393 BLD T20/S7 SW6-T
THDR/L 3232-20T40-IQ PIN 6.5 INJ 7000944 SR M8-26393 BLD T20/S7 SW6-T
THDR/L 4040-20T50-IQ PIN 6.5 INJ 7000944 SR M8-26393 BLD T20/S7 SW6-T
