USER GUIDE
                           •
      GROOVE-TURN  JETCUT Tools High-Pressure (up to 340 bar)   General Information





              The high-pressure coolant feature has been in existence
              for a long time in the metal removal world, taking a bigger
                                                                Pressure Ranges
                                                                Up to 30 bar – Low pressure (LP) may provide some
              role in today’s machining. ISCAR was one of the first
              cutting tools companies to respond to market needs by
                                                                improvement in tool life. Usually will not have an effect on
              designing and producing tools for ultra-high and high-
              pressure coolant flow. High-pressure coolant was initially
                                                                commonly used pressure range used with JETCUT tools.
              implemented mainly for difficult-to-machine materials
                                                                Increase in tool life, increase in cutting speeds, improved
                                                                chip control. 120 – 400 bar – Ultra high-pressure (UHP)
              such as Titanium, Inconel and other heat resistant alloys.   chip control. 30 – 120 bar – High-pressure (HP) the most
              Later it was found that tool life, productivity and chip   requires special tool design in order to take advantage
              control can be improved when machining stainless and   of the extra pressure. Minor increase in tool life compared
              alloyed steel. JETCUT tools are essential and important   to HP range. Ultra high-pressure coolant is usually
              in the aviation, aerospace and medical industries.  implemented for machining Titanium and heat resistant
                                                                alloys when there is a need for very small chips and higher
              How does it work?                                 machining rates.
              The stream velocity of the coolant emitted from the pump   Since 2000, ISCAR has provided hundreds of
              increases as the coolant holes become smaller.  When it   special tools featuring ultra high-pressure coolant
              emerges out of the tool through the nozzle, the velocity   capability for various customers and applications.
              is very high, exerting considerable force on the chips,
              lowering their temperature and protecting the cutting edge   Pressure vs. Flow
              from thermal shock.  High temperature alloys produce a   Each JETCUT tool is designed to work at a certain flow
              very high temperature as they are being cut. By effectively   rate, depending on the pressure. The flow rates are listed
              removing the heat, the chips become less ductile and thus   in the catalog pages for each tool. The user should verify
              easier to break.  Shorter chips are easily managed, they   that the pump can supply the required flow in order to
              do not tangle around the workpiece or machine parts, so   achieve the optimal results. The pump data sheet will
              there is no need to stop the process frequently. Usually in   usually list the maximum flow rate for each pressure range.
              conventional cooling the chip prevents the coolant from
              reaching the insert rake face in the cutting zone. The   Chips & Pressure
              coolant stream of the JETCUT tools is directed precisely   The coolant flow will start to break the chips at a
              between the insert rake face and the flowing chip. This   certain pressure, depending on the specific tool and
              results in longer tool life and a much more reliable process.   the workpiece material. If the chips are not breaking,
                                                                the pressure should be increased until chip control
              The coolant channels of the JETCUT tools          is achieved. Above this pressure, as it is increased
              feature outlets very close to the cutting edges,   the chips become smaller and smaller. It is possible
              thus gaining the following advantages:            to control the size of the chips by modifying the
                                                                pressure in order to achieve the desired chip size.
      TEXT    may be increased by up to 200% when
            •  Shorter machining time – the cutting speed
              machining Titanium & heat resistant alloys
            •  Longer tool life – tool life increases by up to
              100% not only on Titanium and heat resistant
              alloys, but also on stainless and alloy steels
            •  Improved chip control – even on the most ductile and
              problematic materials, small chips can be obtained
            •  Very effective cooling down of the cutting edge,
              which reduces sensitivity to heat fluctuations
            •  Safer and more stable process
                 JETCUT tools provide advantageous performance also when
                 conventional pressure is applied.
