SELECTION GUIDE
PARTING
PARTING

JT-Type J-Type
Based on the J-type chipformer with a • First choice for soft materials, parting tubes,
T-land reinforced frontal cutting edge. small diameters and thin-walled parts
• Provides a solution for the intermediate range • Cutting edge with positive rake
between the strong and negative C-type configuration • Low-to-medium feed
and the positive edged J-type chipformer. W insert

• Can be used on a wide range of materials. f ≈ 26 [mm/rev]

• Same manner as the J-type, but it can be used
at higher feeds due to its reinforced edge.
High Nonferrous Cast
Alloy
Austenitic
f ≈ W insert [mm/rev] Steel Stainless Temp. Materials Iron

24

Alloys
3 3 3 3 7
High
Alloy Austenitic Nonferrous Cast Recommendations are for neutral inserts.
Steel Stainless Temp. Materials Iron For R/L inserts, reduce feed by 20-40%.
Alloys
3 3 3 7 3
4°
5° 7°
Recommended feed range as a function of insert width
7°
Feed
mm/rev
Recommended feed range as a function of insert width
0.25
Feed
mm/rev 0.22
0.30
0.18
0.25
0.14
0.20
0.10
0.15
0.06
0.10
Width 0.02 Width
2 3 4 5 6 7 mm 1.0 1.4 1.6 2.0 3.0 4.0 5.0 6.0 mm

463
