USER GUIDE
          PARTING
                                                                                                                      PARTING





              Clamping / Extraction Instructions                Eccentric Extractor for Insert Indexing
                                                                Simple to operate; controlled rotation requires low
              Extractor for DGN/R/L Double-Ended Inserts        force; guarantees limited upper jaw movement
              Do-Grip Insert Clamping/Extracting                and secures maximum load on blade.













              Extracting the insert

              Grade Application Range
               Cutting Speed


                       IC807 (IC907)


                        IC1010 (IC808)


                             IC354


                             IC1030 (IC830)










                                          Feed / Interrupted cut




             Selection Guide for Parting Grades
                                      ISO P            ISO M      ISO K      ISO N      ISO S      ISO H
                                 1-11       12-13       14        15-20      21-28      31-37      38-41
                                                      Stainless
                                                       Steel
                                           Stainless   Austenitic
                                            Steel     & Duplex                           High
                                           Ferritic &   (Ferritic -                   Temperature  Hard Steel &
                Material groups  Steel    Martensitic  Austenitic)  Cast Iron  Non-ferrous  Alloys  Cast Iron
                       Harder  IC807 (IC907)  IC807 (IC907)  IC807 (IC907)    IC20    IC807 (IC907) IC807 (IC907)
                                            IC808      IC808   IC807 (IC907)             IC20
                                 IC808      IC1010     IC1010      IC20                 IC808       IC808
                                 IC1010     IC5400     IC5400     IC808                 IC1010     IC1010
                                 IC830      IC830      IC830      IC1010                IC830
              PARTING Tougher    IC1030     IC1030     IC1030                           IC1030
                First choice
