· USER GUIDE
MODULAR-GRIP ADAPTATIONS

ISCAR Modular System for Turning Lathes

Toolholder System for MAZAK Machines with MODULAR-GRIP-XL
Adaptation and Directed Internal Coolant

Features and Benefits of Machine-Specific Toolholder Systems
Adaptation Sizes Adaptation Features Reliable Processes

Features: MA4016E MA4020E MA####E

MA4020T

MA5020E MA4016T MA####T

• For Mazak Quick Turn, Hyper • Suitable for any common • Chips do not accumulate in
Quardrex and Multiplex machines Mazak adaptations the work space (no coolant
tube / hose required)
• MA4016E
Benefits: • MA4020E • Reliable coolant supply due
to fixed flow orientation (no
• MA5020E
• MA4016T adjustable coolant nozzle)
• MA4020T
