MODULAR-GRIP ADAPTATIONS

ISCAR Modular System for Turning Lathes

Toolholder System for INDEX ABC Machines with MODULAR-GRIP-XL
Adaptation and Directed Internal Coolant

Features and Benefits of Machine-Specific Toolholder Systems
Adaptation Sizes Height Adjustment +0.2 mm Machine Optimized Tool Design

Features:

• For Index ABC machines turret 2 • Mismatch of turrets can be adjusted • Extremely long tool life due
• Prismatic adaptation • Extremely long tool life due • Reduced vibrations due to
to very stable tool design
to exact center height
Benefits: • Reliable coolant supply due
reduced bar overhang
to fixed flow orientation (no
adjustable coolant nozzle)
