· USER GUIDE

ISCAR Modular System for Turning Lathes

Toolholder Systems for Biglia / EUROTECH, MIYANO and NAKAMURA TOME with
MODULAR-GRIP-XL Adaptation and Directed internal Coolant
Toolholder Systems for Biglia / EUROTECH, Miyano and Nakamura Tome
Nakamura-Tome MODULAR-GRIP ADAPTATIONS

• Holder for Biglia / EUROTECH turrets • Holder for MIYANO turrets • Holder for NAKAMURA-TOME turrets
• BI40 • MI40 • NT55
• BI55 • MI45 • NT65
• MI55
Features and Benefits of Machine-Specific Toolholder Systems
Parting Next to Main Spindle
Optimized Holder Design Reliable Processes
and Sub-Spindle

Features:

• Long tool life due to small bar • Low risk of collision due to • Chips do not accumulate in
the work space (no coolant
optimized tool design
overhang and less vibrations
Benefits: • Slim design • Parting next to main spindle • Reliable coolant supply due
tube / hose required)
• Low risk of collision
or sub-spindle depending on
• Suitable for any machine-
specific clamping device the correspondent length to fixed flow orientation (no
adjustable coolant nozzle)
