· USER GUIDE
MODULAR-GRIP ADAPTATIONS

ISCAR Modular System for Turning Lathes

Toolholder Systems for Turn-Mill Centers with HSK Shank and MODULAR-GRIP-XL
Adaptation and Directed Internal Coolant

Features and Benefits of Machine-Specific Toolholder Systems
Adaptation Sizes Relief for Automatic Tool Changers Reliable Processes

Features: HSK T 40

Relief for tool
exchanger
HSK T 63
• For HSK T turrets and for turn-mill • Tools can be used on machines • Chips do not accumulate in
centers with HSK T milling spindles with an automatic tool exchanger the work space (no coolant
Benefits: • HSK T 40 • Reliable coolant supply due
tube / hose required)
• HSK T 63
to fixed flow orientation (no
flexible coolant nozzle)

All trademarks and logos are the property of their respective companies
