≤ Ø 2.8 > Ø 2.8
~ DIN 40435
PM HSSE
EG M ISO DIN 8140 ~ DIN 40435

N360 3 N360V 3 N460 3 N460V 3

N

N360-3 63 72 73 74 81 91
R40

N360V-3 V 11 12 32
R40

N460-3 63 72 73 74 81 91
R40

< 2.5 x D < 2.5 x D < 2.5 x D < 2.5 x D

N460V-3 V 11 12 32
R40

C C C C
a
d 2
2.5 x P 2.5 x P 2.5 x P 2.5 x P
d 1
l
2
l
3 l P
1
Ø d 1 P d 1 l 1 l 2 l 3 d 2 a ID ID ID ID
EG M mm mm mm mm mm mm mm
2 0.4 2.52 50 9 2.8 2.1 2 2.1 l 101599
2.5 0.45 3.08 56 5.5 18 3.5 2.7 3 2.65 l 101600
3 0.5 3.65 56 6.5 20 4 3 3 3.15 l 101601 l 142813
4 0.7 4.91 70 9 25 6 4.9 3 4.2 l 101602 l 142814
5 0.8 6.04 80 11 30 6 4.9 3 5.25 l 101603 l 142815
6 1 7.3 80 11 30 7 5.5 3 6.3 l 101604 l 142816
8 1.25 9.62 100 14 39 10 8 3 8.4 l 101605 l 142817
10 1.5 11.94 100 14 9 7 3 10.4 l 102335 l 142818
12 1.75 14.27 110 14 11 9 3 12.5 l 102336 l 142819
14 2 16.59 110 18 12 9 3 14.6 l 102337 l 142820
16 2 18.59 125 21 14 11 3 16.6 l 102338 l 142821
