PM DIN 2174
M ISO DIN 13 ~

FPS FPS380DL 3 FPS381DL 3 FPS380VS 3 FPS381VS 3

FPS380DL-3 DLC 63 71 72
73 91 92 94

FPS381DL-3 DLC 63 71 72
73 91 92 94

FPS380VS-3 VS 11 12 13 14

< 1.5 x D < 2.5 x D < 1.5 x D < 2.5 x D

FPS381VS-3 VS 11 12 13 14
15

C C C C
a
d 2
2.5 x P 2.5 x P 2.5 x P 2.5 x P
d 1
l
2
l
3 l P
1
Ø d 1 P l 1 l 2 l 3 d 2 a 6HX Tol. ID ID ID ID
M mm mm mm mm mm mm
3 0.5 56 12 18 3.5 2.7 2.8 + 0.03 l 170553 l 182038 l 166614 l 166616
3.5 0.6 56 13 20 4 3 3.25 + 0.03 l 175347 l 182623 l 166620 l 166622
4 0.7 63 14 21 4.5 3.4 3.7 + 0.03 l 170554 l 182039 l 166627 l 166629
5 0.8 70 15 25 6 4.9 4.65 + 0.03 l 182619 l 178343 l 166635 l 166637
6 1 80 17 30 6 4.9 5.55 + 0.05 l 182620 l 171112 l 166644 l 166646
8 1.25 90 20 35 8 6.2 7.4 + 0.05 l 182621 l 179144 l 166654 l 166656
10 1.5 100 22 39 10 8 9.3 + 0.05 l 182622 l 171113 l 166664 l 166666

Ø d 1 P l 1 l 2 l 3 d 2 a 6HX Tol. ID 6H ID 6H
M mm mm mm mm mm mm + mm + mm
3 0.5 56 12 18 3.5 2.7 2.8 + 0.03 l 166697 0.020 l 166617 0.020
3.5 0.6 56 13 20 4 3 3.25 + 0.03 l 166687 0.021 l 166623 0.021
4 0.7 63 14 21 4.5 3.4 3.7 + 0.03 l 166688 0.022 l 166630 0.022
5 0.8 70 15 25 6 4.9 4.65 + 0.03 l 166689 0.024 l 166638 0.024
6 1 80 17 30 6 4.9 5.55 + 0.05 l 166686 0.026 l 166647 0.026
8 1.25 90 20 35 8 6.2 7.4 + 0.05 l 166740 0.028 l 166657 0.028
10 1.5 100 22 39 10 8 9.3 + 0.05 l 166739 0.032 l 166667 0.032
