~ DIN 2174
PM
M ISO DIN 13 ~ DIN 2174

FAS FAS384VS 3 FAS484VS 3

21 22 23 24
FAS384VS-3 VS
41 51 61

FAS484VS-3 VS 21 22 23 24
41 51 61

< 3 x D < 3 x D

C C
a
d 2
2.5 x P 2.5 x P
d 1
l
2
l
3 l P
1
Ø d 1 P l 1 l 2 l 3 d 2 a 6HX Tol. ID ID
M mm mm mm mm mm mm
3 0.5 56 12 18 3.5 2.7 2.8 + 0.03 l 166741
4 0.7 63 14 21 4.5 3.4 3.7 + 0.03 l 166742
5 0.8 70 15 25 6 4.9 4.65 + 0.03 l 166690
6 1 80 17 30 6 4.9 5.55 + 0.05 l 166691
8 1.25 90 20 35 8 6.2 7.4 + 0.05 l 166692
10 1.5 100 22 39 10 8 9.3 + 0.05 l 166693
12 1.75 110 24 9 7 11.2 + 0.05 l 166694
14 2 110 28 11 9 13.1 + 0.05 l 166695
16 2 110 30 12 9 15.1 + 0.05 l 166696
