~ DIN 2174 DC
PM
M ISO DIN 13 ~ DIN 2174 DC

FPS FPS384VS 3 FPS484VS 3 FPS584VS 3 FPS684VS 3

11 12 13 14
FPS384VS-3 VS
15

FPS484VS-3 VS 11 12 13 14
15

FPS584VS-3 EL VS 11 12 13 14
15

FPS684VS-3 EL VS 11 12 13 14
15
< 3 x D < 3 x D < 3 x D < 3 x D

C C C C
a
d 2
2.5 x P 2.5 x P 2.5 x P 2.5 x P
d 1
l
2
l
3 l P
1
Ø d 1 P l 1 l 2 l 3 d 2 a 6HX Tol. ID ID
M mm mm mm mm mm mm
3 0.5 56 12 18 3.5 2.7 2.8 + 0.03 l 166737
4 0.7 63 14 21 4.5 3.4 3.7 + 0.03 l 166738
5 0.8 70 15 25 6 4.9 4.65 + 0.03 l 166640
6 1 80 17 30 6 4.9 5.55 + 0.05 l 166650
8 1.25 90 20 35 8 6.2 7.4 + 0.05 l 166660
10 1.5 100 22 39 10 8 9.3 + 0.05 l 166670
12 1.75 110 24 9 7 11.2 + 0.05 l 166675
14 2 110 28 11 9 13.1 + 0.05 l 166680
16 2 110 30 12 9 15.1 + 0.05 l 166685

Ø d 1 P l 1 l 2 l 3 d 2 a 6HX Tol. ID ID
M mm mm mm mm mm mm
3 0.5 100 12 18 3.5 2.7 2.8 + 0.03 l 172763
4 0.7 125 14 21 4.5 3.4 3.7 + 0.03 l 172766
5 0.8 140 15 25 6 4.9 4.65 + 0.03 l 172769
6 1 160 17 30 6 4.9 5.55 + 0.05 l 172772
8 1.25 180 20 35 8 6.2 7.4 + 0.05 l 172775
10 1.5 200 22 39 10 8 9.3 + 0.05 l 172778
12 1.75 224 24 9 7 11.2 + 0.05 l 172781
