FAS FAS581VS 3 FAS681VS 3 FAS584VS 3 FAS684VS 3

FAS581VS-3 EL VS
21 22 23 24
41 51 61

FAS681VS-3 EL VS

FAS584VS-3 EL VS
21 22 23 24
41 51 61

FAS684VS-3 EL VS
< 2.5 x D < 2.5 x D < 3 x D < 3 x D

C C C C
a
d 2
2.5 x P 2.5 x P 2.5 x P 2.5 x P
d 1
l
2
l
3 l P
1
Ø d 1 P l 1 l 2 l 3 d 2 a 6HX Tol. ID ID ID ID
M mm mm mm mm mm mm
3 0.5 100 12 18 3.5 2.7 2.8 + 0.03 l 172784 l 172805
4 0.7 125 14 21 4.5 3.4 3.7 + 0.03 l 172787 l 172808
5 0.8 140 15 25 6 4.9 4.65 + 0.03 l 172790 l 172811
6 1 160 17 30 6 4.9 5.55 + 0.05 l 172793 l 172814
8 1.25 180 20 35 8 6.2 7.4 + 0.05 l 172796 l 172817
10 1.5 200 22 39 10 8 9.3 + 0.05 l 172799 l 172820
12 1.75 224 24 9 7 11.2 + 0.05 l 172802 l 172822
