Page 304 - 21-036 APPLITEC catalogue.indb

a p
a e
f z
d 1
v c
n
v f
Application Material [mm] z [m/min] [mm] [mm] [mm] [min ] -1 [mm/min]
Steel 3.00 4 140 0.010 3.000 0.150 14855 594
< 850 N/mm² 4.00 4 140 0.010 4.000 0.200 11140 446
5.00 4 140 0.015 5.000 0.250 8915 535
6.00 6 140 0.015 6.000 0.300 7425 668
8.00 6 140 0.025 8.000 0.400 5570 836
10.00 6 140 0.030 10.000 0.500 4455 802
Steel 3.00 4 100 0.010 3.000 0.150 10610 424
850 - 1100 N/mm² 4.00 4 100 0.010 4.000 0.200 7960 318
5.00 4 100 0.015 5.000 0.250 6365 382
6.00 6 100 0.015 6.000 0.300 5305 478
8.00 6 100 0.025 8.000 0.400 3980 597
10.00 6 100 0.030 10.000 0.500 3185 573
Steel 3.00 4 75 0.010 3.000 0.150 7960 318
1100 - 1300 N/mm² 4.00 4 75 0.010 4.000 0.200 5970 239
5.00 4 75 0.015 5.000 0.250 4775 287
6.00 6 75 0.015 6.000 0.300 3980 358
8.00 6 75 0.025 8.000 0.400 2985 448
10.00 6 75 0.030 10.000 0.500 2385 429

Inox normal 3.00 4 90 0.010 3.000 0.150 9550 382
[Cr-Ni/1.4301] 4.00 4 90 0.010 4.000 0.200 7160 286
[Cr-Ni-Mo/1.4571] 5.00 4 90 0.015 5.000 0.250 5730 344
6.00 6 90 0.015 6.000 0.300 4775 430
8.00 6 90 0.025 8.000 0.400 3580 537
10.00 6 90 0.030 10.000 0.500 2865 516

Cast iron 3.00 4 120 0.010 3.000 0.150 12730 509
(lamellar / spheroidal) 4.00 4 120 0.010 4.000 0.200 9550 382
5.00 4 120 0.015 5.000 0.250 7640 458
6.00 6 120 0.015 6.000 0.300 6365 573
8.00 6 120 0.025 8.000 0.400 4775 716
10.00 6 120 0.030 10.000 0.500 3820 688

Cold work tool steel 3.00 4 65 0.010 3.000 0.150 6895 276
(12% Cr), 4.00 4 65 0.010 4.000 0.200 5175 207
high alloyed 5.00 4 65 0.015 5.000 0.250 4140 248
[1.2379] 6.00 6 65 0.015 6.000 0.300 3450 311
8.00 6 65 0.025 8.000 0.400 2585 388
10.00 6 65 0.030 10.000 0.500 2070 373

Titanium alloys 3.00 4 95 0.010 3.000 0.150 10080 403
up to 300 HB 4.00 4 95 0.010 4.000 0.200 7560 302
[Ti5Al2.5Sn] 5.00 4 95 0.015 5.000 0.250 6050 363
6.00 6 95 0.015 6.000 0.300 5040 454
8.00 6 95 0.025 8.000 0.400 3780 567
10.00 6 95 0.030 10.000 0.500 3025 545

Inox difficult 3.00 4 50 0.010 3.000 0.150 5305 212
[Cr-Ni-Mo++/1.4529] 4.00 4 50 0.010 4.000 0.200 3980 159
Heat resistant steel 5.00 4 50 0.015 5.000 0.250 3185 191
[1.4841] 6.00 6 50 0.015 6.000 0.300 2655 239
8.00 6 50 0.025 8.000 0.400 1990 299
10.00 6 50 0.030 10.000 0.500 1590 286
