          Application      Material     [mm]  z   [m/min]  [mm]  [mm]  [mm]  [min -1 ]  [mm/min] [cm 3 /min]  jZ
                                                                                       [°]
                        Wrought aluminium   6.00  3  500  0.080  9.000  4.800  26525  6366  275.0  20.0°
                        Construction aluminium  8.00  3  500  0.100  12.000  6.400  19895  5969  458.4  20.0°
                                        10.00  3   500  0.120  15.000  8.000  15915  5729  687.5  20.0°
                                        12.00  3   500  0.140  18.000  9.600  13265  5571  962.7  20.0°
                                        16.00  3   500  0.160  24.000  12.800  9945  4774  1466.4  20.0°
                                        20.00  3   500  0.180  30.000  16.000  7960  4298  2063.2  20.0°
                                        25.00  3   500  0.200  37.500  20.000  6365  3819  2864.3  20.0°
                        Al-Gusslegierung  6.00  3  450  0.080  9.000  4.800  23875  5730  247.5  20.0°
                                         8.00  3   450  0.100  12.000  6.400  17905  5372  412.5  20.0°
                                        10.00  3   450  0.120  15.000  8.000  14325  5157  618.8  20.0°
                                        12.00  3   450  0.140  18.000  9.600  11935  5013  866.2  20.0°
                                        16.00  3   450  0.160  24.000  12.800  8950  4296  1319.7  20.0°
                                        20.00  3   450  0.180  30.000  16.000  7160  3866  1855.9  20.0°
                                        25.00  3   450  0.200  37.500  20.000  5730  3438  2578.5  20.0°
                        Unalloyed copper  6.00  3  400  0.072  9.000  4.800  21220  4584  198.0  12.0°
                                         8.00  3   400  0.090  12.000  6.400  15915  4297  330.0  12.0°
                                        10.00  3   400  0.108  15.000  8.000  12730  4125  494.9  12.0°
                                        12.00  3   400  0.126  18.000  9.600  10610  4011  693.0  12.0°
                                        16.00  3   400  0.144  24.000  12.800  7960  3439  1056.4  12.0°
                                        20.00  3   400  0.162  30.000  16.000  6365  3093  1484.8  12.0°
                                        25.00  3   400  0.180  37.500  20.000  5095  2751  2063.5  12.0°
                                                  v c
                                                                                        LR
                                                       f z
                                                           a p
                                                                              Q
                                                                a e
                                                                         v f
                                        d 1
                                                                     n
          Application      Material     [mm]  z  [m/min]  [mm]  [mm]  [mm]  [min ]  [mm/min] [cm /min]  jR   [mm]
                                                                                   [°]
                                                                      -1
                                                                              3
                        Wrought aluminium   6.00  3  450  0.072  9.000  6.000  23875  5157  278.5  25.0°  19.3
                        Construction aluminium  8.00  3  450  0.090  12.000  8.000  17905  4834  464.1  25.0°  25.7
                                        10.00  3  450  0.108  15.000  10.000  14325  4641  696.2  25.0°  32.2
                                        12.00  3  450  0.126  18.000  12.000  11935  4511  974.5  25.0°  38.6
                                        16.00  3  450  0.144  24.000  16.000  8950  3866  1484.7  25.0°  51.5
                                        20.00  3  450  0.162  30.000  20.000  7160  3480  2087.9  25.0°  64.3
                                        25.00  3  450  0.180  37.500  25.000  5730  3094  2900.8  25.0°  80.4
                        Al-Gusslegierung  6.00  3  405  0.072  9.000  6.000  21485  4641  250.6  25.0°  19.3
                                        8.00  3   405  0.090  12.000  8.000  16115  4351  417.7  25.0°  25.7
                                        10.00  3  405  0.108  15.000  10.000  12890  4176  626.5  25.0°  32.2
                                        12.00  3  405  0.126  18.000  12.000  10745  4062  877.3  25.0°  38.6
                                        16.00  3  405  0.144  24.000  16.000  8055  3480  1336.2  25.0°  51.5
                                        20.00  3  405  0.162  30.000  20.000  6445  3132  1879.4  25.0°  64.3
                                        25.00  3  405  0.180  37.500  25.000  5155  2784  2609.7  25.0°  80.4
                        Unalloyed copper  6.00  3  320  0.058  9.000  6.000  16975  2954  159.5  15.0°  33.6
                                        8.00  3   320  0.072  12.000  8.000  12730  2750  264.0  15.0°  44.8
                                        10.00  3  320  0.086  15.000  10.000  10185  2628  394.2  15.0°  56.0
                                        12.00  3  320  0.101  18.000  12.000  8490  2573  555.7  15.0°  67.2
                                        16.00  3  320  0.115  24.000  16.000  6365  2196  843.2  15.0°  89.6
                                        20.00  3  320  0.130  30.000  20.000  5095  1987  1192.3  15.0°  112.0
                                        25.00  3  320  0.140  37.500  25.000  4075  1712  1604.5  15.0°  140.0
