Application Material [mm] z [mm] [mm] [mm] n=10000min -1 n=15000min -1 n=20000min -1 n=30000min -1
v f
v f
v f
v f
[mm/min] [mm/min] [mm/min] [mm/min]
Wrought aluminium 6.00 6 0.020 18.000 0.100 1200 1800 2400 3600
Construction aluminium 8.00 6 0.020 24.000 0.100 1200 1800 2400 3600
10.00 6 0.025 30.000 0.150 1500 2250 3000 4500
12.00 6 0.025 36.000 0.200 1500 2250 3000 4500
16.00 6 0.030 48.000 0.250 1800 2700 3600 5400
20.00 6 0.030 60.000 0.300 1800 2700 3600 5400
Unalloyed copper 6.00 6 0.020 18.000 0.100 1200 1800 2400 3600
8.00 6 0.020 24.000 0.100 1200 1800 2400 3600
10.00 6 0.025 30.000 0.150 1500 2250 3000 4500
12.00 6 0.025 36.000 0.200 1500 2250 3000 4500
16.00 6 0.030 48.000 0.250 1800 2700 3600 5400
20.00 6 0.030 60.000 0.300 1800 2700 3600 5400
Thermoplastics 6.00 6 0.020 18.000 0.100 1200 1800 2400 3600
8.00 6 0.020 24.000 0.100 1200 1800 2400 3600
10.00 6 0.025 30.000 0.150 1500 2250 3000 4500
12.00 6 0.025 36.000 0.200 1500 2250 3000 4500
16.00 6 0.030 48.000 0.250 1800 2700 3600 5400
20.00 6 0.030 60.000 0.300 1800 2700 3600 5400
Cast aluminium 6.00 6 0.020 18.000 0.100 1200 1800 2400 3600
8.00 6 0.020 24.000 0.100 1200 1800 2400 3600
10.00 6 0.025 30.000 0.150 1500 2250 3000 4500
12.00 6 0.025 36.000 0.200 1500 2250 3000 4500
16.00 6 0.030 48.000 0.250 1800 2700 3600 5400
20.00 6 0.030 60.000 0.300 1800 2700 3600 5400
