Series V4S, V4R, V4B (continued)

.2500" - .3150"
(6.350mm - 8.000mm)

d1 † d2 l1 l2 r l3 d3 END MILLS HIGH PERFORMANCE
EDP# Diameter Shank Overall Flute Corner Reach Neck
(plain) (weldon) Decimal Metric Diameter Length Length Radius Length Diameter
NEW 50654 - .2500 1/4" 6.350 1/4" 4" 1-1/2" - - -
NEW 50681 - .2500 1/4" 6.350 1/4" 4" 1-1/2" BALL - -
NEW 50655 - .2500 1/4" 6.350 1/4" 4" 1-3/4" - - -
NEW 50718 - .2500 1/4" 6.350 1/4" 4" 1-3/4" .020" - -
NEW 50682 - .2500 1/4" 6.350 1/4" 4" 1-3/4" BALL - -
NEW 50656 - .2500 1/4" 6.350 1/4" 4" 2" - - -
NEW 50683 - .2500 1/4" 6.350 1/4" 4" 2" BALL - -
NEW 50651 - .2500 1/4" 6.350 1/4" 3" 3/8" - 1-1/8" .237"
NEW 50678 - .2500 1/4" 6.350 1/4" 3" 3/8" BALL 1-1/8" .237"
50600 - .2500 1/4" 6.350 1/4" 4" 3/8" - 1-1/8" .237"
50211 - .2500 1/4" 6.350 1/4" 4" 3/8" .015" 1-1/4" .230" 70 6
50474 - .2500 1/4" 6.350 1/4" 4" 3/8" BALL 1-1/8" .237"
NEW 50679 - .2500 1/4" 6.350 1/4" 4" 3/8" BALL 1-1/2" .237"
NEW 50652 - .2500 1/4" 6.350 1/4" 4" 3/8" - 2" .237"
NEW 50680 - .2500 1/4" 6.350 1/4" 4" 3/8" BALL 2" .237"
NEW 50719 - .2500 1/4" 6.350 1/4" 6" 3/8" .010" 4" .230"
NEW 50680 - .2500 1/4" 6.350 1/4" 6" 3/8" BALL 4" .230"
NEW 50720 - .3125 5/16" 7.937 5/16" 2" 3/8" .030" - -
50541 - .3125 5/16" 7.937 5/16" 2" 7/16" - - -
50622 - .3125 5/16" 7.937 5/16" 2" 7/16" .010" - -
50624 - .3125 5/16" 7.937 5/16" 2" 7/16" .015" - -
50492 - .3125 5/16" 7.937 5/16" 2" 7/16" .020" - -
NEW 50721 - .3125 5/16" 7.937 5/16" 2" 7/16" .125" - -
50561 - .3125 5/16" 7.937 5/16" 2" 7/16" BALL - -
50239 - .3125 5/16" 7.937 5/16" 2-1/2" 13/16" - - -
50626 - .3125 5/16" 7.937 5/16" 2-1/2" 13/16" .010" - -
50628 - .3125 5/16" 7.937 5/16" 2-1/2" 13/16" .015" - -
50212 - .3125 5/16" 7.937 5/16" 2-1/2" 13/16" .020" - -
50213 - .3125 5/16" 7.937 5/16" 2-1/2" 13/16" .030" - -
NEW 50722 - .3125 5/16" 7.937 5/16" 2-1/2" 13/16" .060" - -
NEW 50723 - .3125 5/16" 7.937 5/16" 2-1/2" 13/16" .125" - -
50255 - .3125 5/16" 7.937 5/16" 2-1/2" 13/16" BALL - - 35 6
NEW 50657 - .3125 5/16" 7.937 5/16" 3" 1-1/4" - - -
NEW 50724 - .3125 5/16" 7.937 5/16" 3" 1-1/4" .015" - -
NEW 50725 - .3125 5/16" 7.937 5/16" 3" 1-1/4" .030" - -
NEW 50726 - .3125 5/16" 7.937 5/16" 3" 1-1/4" .060" - -
NEW 50685 - .3125 5/16" 7.937 5/16" 3" 1-1/4" BALL - -
NEW 50658 - .3125 5/16" 7.937 5/16" 3" 7/16" - 1-1/2" .295"
NEW 50686 - .3125 5/16" 7.937 5/16" 3" 7/16" BALL 1-1/2" .295"
50602 - .3150 8.000 8.0 50 12 - - -
50630 - .3150 8.000 8.0 50 12 0.50 - - MATERIAL HARDNESS (Rc)
50240 - .3150 8.000 8.0 65 22 - - -
50214 - .3150 8.000 8.0 65 22 0.50 - -
50356 - .3150 8.000 8.0 65 22 0.75 - -
50215 - .3150 8.000 8.0 65 22 1.00 - -
NEW 50727 - .3150 8.000 8.0 65 22 1.20 - -
50357 - .3150 8.000 8.0 65 22 1.50 - -
50358 - .3150 8.000 8.0 65 22 2.00 - -
NEW 50728 - .3150 8.000 8.0 65 22 3.00 - -
50256 - .3150 8.000 8.0 65 22 BALL - -
