Page 145 - GARR_TOOL(CATALOG_INT)

Series V4S, V4R, V4B (continued)

.5000" - .6250"
(12.700mm - 15.875mm)

d1 † d2 l1 l2 r l3 d3 END MILLS HIGH PERFORMANCE
EDP# Diameter Shank Overall Flute Corner Reach Neck
(plain) (weldon) Decimal Metric Diameter Length Length Radius Length Diameter
NEW 50668 - .5000 1/2" 12.700 1/2" 6" 3" - - -
NEW 50795 - .5000 1/2" 12.700 1/2" 6" 3" .020" - -
NEW 50796 - .5000 1/2" 12.700 1/2" 6" 3" .030" - -
NEW 50797 - .5000 1/2" 12.700 1/2" 6" 3" .060" - -
NEW 50798 - .5000 1/2" 12.700 1/2" 6" 3" .120" - -
NEW 50799 - .5000 1/2" 12.700 1/2" 6" 3" .190" - -
NEW 50699 - .5000 1/2" 12.700 1/2" 6" 3" BALL
50610 - .5000 1/2" 12.700 1/2" 4" 5/8" - 2-1/4" .475"
50228 - .5000 1/2" 12.700 1/2" 4" 5/8" .020" 2-1/4" .470"
NEW 50900 - .5000 1/2" 12.700 1/2" 4" 5/8" .030" 2-1/4" .470"
NEW 50901 - .5000 1/2" 12.700 1/2" 4" 5/8" .060" 2-1/4" .470"
NEW 50902 - .5000 1/2" 12.700 1/2" 4" 5/8" .120" 2-1/4" .470" 70 6
50478 - .5000 1/2" 12.700 1/2" 4" 5/8" BALL 2-1/4" .475"
NEW 50667 - .5000 1/2" 12.700 1/2" 6" 5/8" - 3-1/8" .475"
50235 - .5000 1/2" 12.700 1/2" 6" 5/8" - 4-1/8" .475"
50594 - .5000 1/2" 12.700 1/2" 6" 5/8" .020" 4-1/8" .470"
50596 - .5000 1/2" 12.700 1/2" 6" 5/8" .030" 4-1/8" .470"
NEW 50697 - .5000 1/2" 12.700 1/2" 6" 5/8" BALL 3-1/8" .475"
50598 - .5000 1/2" 12.700 1/2" 6" 5/8" BALL 4-1/8" .475"
NEW 50698 - .5000 1/2" 12.700 1/2" 6" 1" BALL 4-1/2" .475"
50545 50546 .6250 5/8" 15.875 5/8" 3" 3/4" - - -
NEW 50903 - .6250 5/8" 15.875 5/8" 3" 3/4" .010" - -
NEW 50904 - .6250 5/8" 15.875 5/8" 3" 3/4" .015" - -
50498 50499 .6250 5/8" 15.875 5/8" 3" 3/4" .020" - -
50500 50501 .6250 5/8" 15.875 5/8" 3" 3/4" .030" - -
50502 50503 .6250 5/8" 15.875 5/8" 3" 3/4" .060" - -
NEW 50905 - .6250 5/8" 15.875 5/8" 3" 3/4" .090" - -
NEW 50906 - .6250 5/8" 15.875 5/8" 3" 3/4" .120" - -
NEW 50907 - .6250 5/8" 15.875 5/8" 3" 3/4" .125" - -
NEW 50908 - .6250 5/8" 15.875 5/8" 3" 3/4" .156" - -
NEW 50909 - .6250 5/8" 15.875 5/8" 3" 3/4" .190" - -
NEW 50910 - .6250 5/8" 15.875 5/8" 3" 3/4" .250" - -
50246 50286 .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" - - - 35
NEW 50911 - .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .010" - - 6
NEW 50912 - .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .015" - -
50229 50277 .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .020" - -
50534 50535 .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .030" - -
50536 50537 .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .040" - -
50538 50539 .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .060" - -
NEW 50913 - .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .090" - -
50230 50278 .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .120" - -
NEW 50914 - .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .125" - -
NEW 50915 - .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .156" - - MATERIAL HARDNESS (Rc)
NEW 50916 - .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .190" - -
NEW 50917 - .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .250" - -
50262 50294 .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" BALL - -

0 6
continued ?
