      INDEXABLE DRILLS    and Drilling in One Operation    Dimensions                               Tough 1   Hard
          XCGT-DT
          Inserts used on Chamfering
          Drill Holders for Chamfering
                                                                 INSL






                                                                                                             IC808
                                                                                                       IC08
           Designation
                                                                       S
           XCGT 060300-30DT
                                  6.18
                                                                                         30.0
                                                    12.30
                                                                                                            •
                                                                                                      •
           XCGT 060300-45DT
                                                                                         45.0
                                  6.18
                                                    12.30
                                                                       2.80
                                                                                                      •
                                                                                                            •
                                  6.18
                                                                       2.80
                                                    12.30
           XCGT 060300-60DT
                                                                                         60.0
                                                                                                            •
                                                                                                      •
                                  8.50
                                                                       3.30
                                                                                         30.0
                                                    16.00
           XCGT 090300-30DT       W1                INSL               2.80              PNA          •     •
           XCGT 090300-45DT       8.50              16.00              3.30              45.0         •     •
           XCGT 090300-60DT       8.50              16.00              3.30              60.0         •     •
          For tools, see pages: CHAMRING (139)

                                                                      OAL
                                          DC_2 m7           LCF                  LS
                                                  PL
                                                        SDL
          SCDT
          Pre-Thread Solid Carbide           DC  140°                                       DCONMSh6
          Drills with Coolant Holes                              45°
                                                         LU
                                                                Dimensions
                                                                                                             IC908
           Designation          DC     SDL   DCONMS  FTDZ (1)  DC_2   PL      LU     LCF     OAL     LS
           SCDT 025-009-060-M3  2.50   8.8    6.00     M3     4.00   0.450   16.00   20.0    62.00   36.0   •
           SCDT 033-011-060-M4  3.30   11.4   6.00     M4     4.50   0.600   19.00   24.0    62.00   36.0   •
           SCDT 042-014-060-M5  4.20   13.6   6.00     M5     5.50   0.760   22.00   28.0    66.00   36.0   •
           SCDT 050-017-080-M6  5.00   16.5   8.00     M6     6.60   0.910   27.00   34.0    79.00   40.0   •
           SCDT 068-021-100-M8  6.80   21.0   10.00    M8     9.00   1.240   38.00   47.0    89.00   40.0   •
           SCDT 085-026-120-M10  8.50  25.5   12.00   M10     11.00  1.550   45.00   55.0    102.00  40.0   •
          •  For user guide and cutting conditions, see pages 175-184
          (1)  Used for standard thread size
