P. 144

CNT
      MULTIFUNCTION TOOLS

          DRG-MF                                   Fig. 1   DC  Please note that the redesigned tools with eliminated countersink will be
          The DRG-MF multifunction drilling, boring, facing, external and internal
                                                                                DCONMS
          Multifunction Drilling, Boring,                     available when the current stock runs out.
          turning and grooving tools have been redesigned due to elimination
          Facing, External Turning and                           LU       LS
                                                                LPR=LF
          of the countersink.                                 In the near future, end-users may encounter
          Internal Grooving Tools
                                                        ±0.05  drilling tools from both designs.
                                                   Fig. 2
          It is very important to explain that this modification has no influence   WF  ±0.05  DMIN
          on performance but in fact extends application range capabilities.                       Right-hand shown
           Designation            DC   DMIN   WF     LU    LPR    LS  DCONMS  CNT   Insert  Fig.
           DR-MF-08R/L-2.25D-12A-04  8.00  8.00  -   18.0  22.5  42.0  12.00  G 1/16  XCMT 04...  1  SR 18034/HG-P  IP-6/5
           DRG-MF-10R/L-2.25D-12A-05  10.00  12.00  7.10  22.5  27.5  42.0  12.00  G 1/16  XCMT 05...  2  SR 20038/HG-P  IP-6/5
           DRG-MF-12R/L-2.25D-16A-06  12.00  14.50  8.50  27.0  33.0  45.0  16.00  G 1/8  XCMT 06...  2  SR 22052/HG-P  IP-7/5
           DRG-MF-14R/L-2.25D-16A-07  14.00  16.50  9.50  31.5  38.5  45.0  16.00  G 1/8  XCMT 07...  2  SR 25064/HG-P  IP-8/5
           DRG-MF-16R/L-2.25D-20A-08  16.00  19.00  11.10  36.0  44.0  50.0  20.00  G 1/8  XCMT 08...  2  SR 30070/HG-P  IP-9/151
                                                                              G 1/8
                                                                       25.00
                                                                                   XCMT 10...
           DRG-MF-20R/L-2.25D-25A-10  20.00  23.50  13.20  45.0  55.0  56.0  Fig. 2. DRG-MF tool  2  SR 35088I/HG-P  IP-10/151
                      Fig. 1. DRG-MF tool
                      with countersink
           DRG-MF-25R/L-2.25D-32A-13  25.00  29.00  16.50  56.5  69.0  61.0  without countersink (modified)   2  SR 45A100I/HG  IP-20/51
                                                                                   XCMT 13...
                                                                       32.00
                                                                              G 1/8
                                       36.50
                                  32.00
           DRG-MF-32R/L-2.25D-40A-17
          The modification will be applied to all DRG-MF tools.  20.50  72.0  86.0  74.0  40.00  G 1/8  XCMT 17...  2  SR 45A100I/HG  IP-20/51
          •  In non-rotating applications, hole diameter can be adjusted within the specified range by shifting drill's center line along machine's X-axis   • The tools feature internal coolant
          holes
          The modified design is being integrated into production
          For inserts, see pages: XCMT-MF (143) • XCMT-MG (143)
          batches starting from January 2020.
          Typical Applications                                                        DRG-MF
          External        Internal              External         Internal
          Radial adjustment (O -center drilling)
          Radial Adjustment (off-center drilling)
          Radial adjustment is dependent on drill diameter
                                                      Holder    Drill dia.  Dmin      Dmax
                                                   DRG-MF 8        8        7.86       8.35
                                                   DRG-MF 10      10        9.82       10.60
                                                   DRG-MF 12      12        11.82      12.60
                                                   DRG-MF 14      14        13.80      14.60
                                                   DRG-MF16       16        15.76      16.50
                                                   DRG-MF 20      20        19.80      20.60
                                                   DRG-MF 25      25        24.80      25.80
                                                   DRG-MF 32      32        31.80      33.00
