Tool Grades
Brazed Drill Heads
Coating
DSD-E0 DSD-E1 DSD-E2/E3 DDD-E3
Application Grade Features
Main Thickness
composition / µm
1122 DEEP DRILLING - BTA SYSTEM
P P10 - P30
K K15 - K25 TiAlCr 2.5 • High wear resistance 3 3 3 3
• Suitable for steel, cast iron,
N N15 - N25 and difficult-to-cut material
S S15 - S25
H H15 - H25
1132 • Good balance between wear
and chipping resistance
TiAlCr 2.5 • Suitable for steel and 3 3
P P20 - P30 stainless steel under general
cutting conditions
M M25 - M35
2122 • High fracture resistance
TiAlCr 2.5 • Suitable for stainless steel 3 3
M M30 - M40
3112
M M15 - M25
K K10 - K20 TiAlCr 2.5 • Good balance between wear 3 3
N N15 - N25 and fracture resistance
S S15 - S25
H H15 - H25
3132
K K15 - K25 • First choice for heat-resistant alloy
N N10 - N20 TiAlCr 2.5 under general cutting conditions 3 3 3
S S15 - S25
H H15 - H25
Note: Being brazed tools, the grade codes represent the grade combination of the brazed carbide tip and guide pad grades.
