USER GUIDE
                                                                                                                      GUNDRILLS



          Delivery Schedule Based on Drill Dimensions for Carbide Tipped Gundrills

            Single Flute Carbide Tipped Gundrill              Single Flute Solid Carbide Gundrill
            Designations New Tools                            Designation New Tools
                    (1)
            Standard  Brazed Drill (Carbide Tipped):          4-6 weeks delivery for any kind of solid cabide gundrill
            Ordering Example:
                                                                      (1)
            STGD - 05500      - 0500 - 57       - IC08        Standard  Solid Carbide Drills
                    Drill Diameter  Overall   Offer No. or   Version No.   Ordering Example:
                               Length  Drawing No.  or Drawing  STCGD   - 05500    - 0200        - 05
            Ø2.5 to Ø20 each 0.1 mm and Ø20 to Ø32 each 1 mm             Drill Diameter  Overall Length  Driver Type
            Standard geometry suitable in any material Standard
                                                                           (1)
            driver from the table (page 301) 1-2 weeks delivery  Semi-Standard  Solid Carbide Drills
                                                              Ordering Example:
                          (1)
            Semi-Standard  Brazed Drill (Carbide Tipped):     CGD - 05520   - 0200  - 05  - CPIC08
            Ordering Example:                                       Drill    Overall   Driver   C=Drill Profile
            GD - 05520   - 0500     - ER       - IC908 (2)          Diameter  Length  Type  P=Polished (R=Rough)
                 Drill     Overall   Offer No. or   carbide                                IC08=Carbide Grade (2)
                 Diameter  Length    Drawing No.  grade (2)
                                                                    (1)
            Diameter out of standard range Standard geometry and/  Special  Solid Carbide Gundrills
            or head profile from page 300 and/or coating Standard   Ordering Example:
            driver from the table (page 301) 3-4 weeks delivery  SPCGD - 05520  - 0500   - 02051   - 01
                                                                       Drill     Overall   Offer No.   Version
            Special  Gundrill Carbide Tipped:                          Diameter  Length    or Drawing  No.
                   (1)
            Ordering Example:                                                              No.
            SPGD - 05520   - 0500   - 02051    - 01           Repair of a solid carbide drill is not possible
                    Drill   Overall   Offer No. or   Version No.    (1)
                    Diameter  Length  Drawing No.             Special  Two Flute Carbide Tipped
            Any special specification (special geometry,      Gundrill Designations
            special driver, etc.) 3-4 weeks delivery          Ordering Example:
                                                              GD2L    - 05520   - 0500  - 02051    - 01
            Repair (Replacement of the Carbide Tip)                    Drill     Overall   Offer No.    Version
                                                                       Diameter  Length  or         No.
                             (1)
            Repair of Standard  Drills                                                   Drawing No.
            Ordering Example:                                 Standard Geometry Resharpening of
            RSTGD - 05520      - 0500      - IC08             Carbide Tipped or Solid Gundrills
                     Drill Diameter  Overall Length  (The only available   (See page 299)
                                            carbide grade)    Ordering Example:
                                                              STGRIND - 05520
            Repair of Semi-Standard (1)                                  Drill
            Ordering Example:                                            Diameter
            RGD - 05520 - 0500    - GR        - IC508 (2)
                  Drill   Overall   G=Drill Profile   (carbide   Special Geometry Resharpening
                  Diameter  Length  R=Rough    grade) (2)     Ordering Example:
                                   (P=Polished)               SPGRIND - 05520   - 0205  - 02051   - 01
                                                                         Drill   Overall   Offer No.   Version
            Repair of Special  Drills                                    Diameter  Length          No.
                           (1)
            Ordering Example:
            RSPGD - 05520    - 0500   - 02051  - 01
                     Drill     Overall   Offer No.    Version No.
                     Diameter  Length  or        or Drawing
                                       Drawing
                                       No.


            Standard gundrills: delivery within 1-2 weeks from order (shipment time not included).
            Semi-standard gundrills: delivery within 2-4 weeks from order (shipment time not included)
            Special gundrills: delivery within 8-10 weeks from order (shipment time not included)
            Available carbide grades: IC08 – uncoated grade used as a substrate for the following coated grades: IC908 (TiAlN); IC508 (TiCN+TiN);
            IC308 (TiCN); IC208 (TiN)
