USER GUIDE
GUNDRILLS Standard Drivers for Gundrill Machines F F

BRAZED GUNDRILL
F = CYLINDRICAL TUBE SOLID CARBIDE
GUNDRILL
Max. Equal or less More
Driver cutting than max. cutting than max. F = Straightening
Driver Type Drawing DXL code diameter diameter diameter extension
CM1 N°45 9.599 10 20
CM2 N°46 14.599 10 20
DIN228AK
CM3 N°47 21.499 10 25
CM4 N°48 29.499 10 25
CM1 N°49 9.599 10 20
CM2 N°50 14.599 10 20
DIN228BK
CM3 N°51 21.499 10 25
CM4 N°52 29.499 10 25
6x30 N°53 2.749 10 20 20
10x40 N°54 7.299 10 20 15
Central L 16x45 N°55 12.399 10 20
Clamping D .750x2.75” N°56 14.899 10 20
Surface 15° 25x70 N°57 19.509 10 25
1.00x2.75” N°58 19.509 10 25
1.25x2.75” N°59 25.609 10 25
1.50x2.75” N°60 32.609 10 25
Frontal L
Clamping D 16x50 N°61 12.399 10 20
Surface 15°
10x50 M6X0.5 N°62 7.299 10 20 15
10x60 M6X0.5 N°63 7.299 10 20
L
Cylindrical M .50x1.97” M6x0.5 N°64 8.999 10 20 15
with Thread D 16x80 M10X1 N°65 12.399 10 20 15
25x100 M16x1.5 N°66 19.509 10 25
36x120 M24x1.5 N°67 30.609 10 25
10x68 M6x0.5 N°68 6.749 10 20
L
D M 16x90 M10x1 N°69 10.799 10 20 15
VDI Design
25x112 M16x1.5 N°70 19.509 10 25
36x135 M24x1.5 N°71 30.609 10 25
Central L 25x70 N°72 19.509 10 25
Clamping D
Hexagonal 32x70 N°73 25.609 10 25
.50x1.50” N°74 8.599 10 20 15
Central L
16x70
Clamping D .75x2.75” N°75 12.099 10 20 15
Tapered 20x70 N°76 14.099 10 20 15
16.099
N°77
10
20
.50x1.50” N°78 9.699 10 20
.75x2.75” N°79 14.899 10 20
1.00x2.75” N°80 19.509 10 25
Frontal L 1.00x3.94”
Clamping D 1.25x2.75” N°81 19.509 10 25
Surface 2° N°82 25.609 10 25
1.25x3.94” N°83 25.609 10 25
1.50x2.75” N°84 32.609 10 25
1.50x3.94” N°85 32.609 10 25
16x112 Tr 16x1.5 N°86 13.599 10 20
Trapezoidal L 20x126 Tr 20x2 N°87 17.099 10 20
Thread Tr D 28x126 Tr 28x2 N°88 25.599 10 25
36x162 Tr 36x2 N°89 32.599 10 25
Spraymist L 16x40 N°90 12.399 10 20
Driver D 25x50 N°91 19.509 10 25
35x60 N°92 26.599 10 25
