L5
RM-SEI-C a°
Single-Edged Reaming Inserts 75° S
for Aluminum and Brass
W1 REAMERS
L

Dimensions

Designation SSC (1) a° L W1 S PLGL IC07
RM-SEI-1C-12 1.0 12 15.50 2.80 1.50 0.550 •
RM-SEI-2C-12 2.0 12 15.50 3.60 1.50 0.550 •
RM-SEI-3C-12 3.0 12 17.00 4.40 2.00 0.550 •
RM-SEI-4C-12 4.0 12 22.50 6.60 3.00 0.550 •
• Lead type of insert should be compatible with lead type of the tool • Available on request
(1) Insert size

Lmax

RM SETTING DEVICE
Reamer Setting Device
dmax
l1

Designation L max l1 d max kg
RM SETTING DEVICE 265.0 450.00 170.0 25.00
