INDEXABLE DRILLS  QCP-2M  (continued)                 DC   Dimensions  LF  PL SIG                      IC908

         Exchangeable Double Margin
         & Self-Centering Drilling Heads
         for DCN Drills, for Machining
         ISO P Materials with High
         Surface Finish Results







                                      DC
                                                                    PL
                                                     LF
           Designation
                                                                                                 24.0
                                                                                  136
           QCP 247-2M
                                                                                                            •
           QCP 249-2M
                                                                                  136
                                                    10.10
                                     24.90
                                                                   5.210
                                                                                                 24.0
                                                                                                            •
           QCP 250-2M
                                                                                                 25.0
                                                    10.70
                                     25.00
                                                                   5.280
                                                                                  136
                                                                                                            •
           QCP 251-2M                24.70          10.14          5.170          SIG           SSC (1)     •
                                                                   5.300
                                                    10.68
                                                                                  136
                                     25.10
                                                                                                 25.0
           QCP 252-2M                25.20          10.66          5.320          136            25.0       •
           QCP 253-2M                25.30          10.64          5.340          136            25.0       •
           QCP 254-2M                25.40          10.62          5.360          136            25.0       •
           QCP 255-2M                25.50          10.60          5.380          136            25.0       •
           QCP 256-2M                25.60          10.58          5.400          136            25.0       •
           QCP 2567-2M               25.67          10.56          5.420          136            25.0       •
           QCP 257-2M                25.70          10.56          5.420          136            25.0       •
           QCP 258-2M                25.80          10.54          5.440          136            25.0       •
           QCP 259-2M                25.90          10.52          5.460          136            25.0       •
          •  Can provide high surface finish of up to 1.6 Ra hole cylindricity and straightness of up to 0.05 mm   •  For cutting conditions see page 68-81
          (1)  Seat size code
          For tools, see pages: DCN A-1.5D (4) • DCN R-1.5D (5) • DCN A-3D (6) • DCN R-3D (7) • DCN A-5D (8) • DCN R-5D (9) • DCN A-8D (10) • DCN R-8D (11)
          •  DCN R-10D (11) • DCN R-12D (12) • DCN C-3D (13) • DCN C-5D (13) • DCN C-12D (14) • DCNS-3D (15) • DCNS-5D (16) • DCNM (17) • DCNT (M8-M24) (136)
          •  MNSNT (293)
