THREAD MILLING TOOLS
                                                                         PDX

          MT3-U60D
          60° Partial Profile Laydown                            INSL
          U-Type Thread Milling Inserts
          for General Industry
                                                                      IC

                TP   NUT                                      Dimensions

              55°
                RE=0.137TP
                   SCREW
                                                  TPN_   TPX_                  TPIN_  TPIX_
           Designation       IC    TPN (1)  TPX (2)  DF2 (3)  DF2 (4)  TPIN (5)  TPIX (6)  DF2 (7)  DF2 (8)  INSL  PDX  IC908
           MT3 11U60D        6.35   2.500  4.000  2.000  3.000   6.00   10.00  8.00   12.00  11.00   5.0    •
           MT3 16U60D        9.52   4.000  6.000  3.000  5.000   4.00   6.00   5.00    8.00  16.49   7.6    •
          •  For technical information and detailed cutting data, see pages 435-442
          (1)  Internal thread pitch minimum
          (2)  Internal thread pitch maximum
          (3)  External thread pitch minimum
          (4)  External thread pitch maximum
          (5)  Internal threads per inch minimum
          (6)  Internal threads per inch maximum
          (7)  External threads per inch minimum
          (8)  External threads per inch maximum
          For tools, see pages: MTSR M.I. S.P.-U (419)



                                                                     PDX

          MT3-55D
          55° Partial Profile Laydown                              IC
          Thread Milling Inserts                                           INSL
          for General Industry


                TP   NUT
                                                              Dimensions
              55°
                RE=0.137TP
                   SCREW
           Designation           IC             TPIX (1)        TPIN (2)        INSL            PDX          IC908
           MT3 1155D             6.35           24.00           14.00           11.00            1.0        •
           MT3 1655D             9.52           12.00            8.00           16.49            1.8        •
          •  For detailed cutting data, see pages 435-442
          (1)  Threads per inch maximum
          (2)  Threads per inch minimum
          For tools, see pages: MTSR M.I. S.P. (419)





                                                                            PDX

          MT3-U55D
          55° Partial Profile Laydown                               INSL
          U-Type Thread Milling Inserts
          for General Industry
                                                                          IC

                TP   NUT
                                                              Dimensions
              55°
                RE=0.137TP
                   SCREW
           Designation           IC             TPIX (1)        TPIN (2)        INSL            PDX          IC908
           MT3 11U55D            6.35           12.00            7.00           11.00            5.0        •
           MT3 16U55D            9.52            6.00            4.50           16.49            7.6        •
          •  For detailed cutting data, see pages 435-442
          (1)  Threads per inch maximum
          (2)  Threads per inch minimum
          For tools, see pages: MTSR M.I. S.P.-U (419)
