FLEXFIT • CLICKFIT S M-CF THSZWS 21.00 DF 140.0 DCONMS 139.10 8 44.00 LBX LSCMS BHTA BD DCONMS A 58-60 HRc kg
0.005
A
LSCMS
LU
BHTA
CLICKFIT to FLEXFIT Adapters
THSZWS

DF
BD
LU
Designation
LBX
S M12-L85/3.30-CF4
81.30
85.0
25.00
M12
4.4
42.00
0.23
S M12-L140/5.50-CF4
M12
21.00
0.98
44.00
42.00
4.4
25.00
S M16-L130/5.11-CF4
29.00
42.00
M16
0.23
126.80
25.00
44.00
130.0
2.6
168.60
25.00
29.00
170.0
2.0
42.00
S M16-L170/6.70-CF4
44.00
M16
1.30
SHANK SM...CF4 CDP...
2 1 A 0.005 A 58-60 HRc
CAB M-M (FLEXFIT) DRVS BHTA BD
Reducers and Extensions
with Coolant Holes for the THSZMS THSZWS BD DCONMS THSZMS THSZWS
Modular FLEXFIT System LSCMS LPR DRVS LU
LSCMS LPR
CAB M-M-C CAB M-M
Designation THSZWS THSZMS BD LPR LU DCONMS LSCMS DRVS (1) Fig. BHTA kg
CAB M06M08 M06 M08 9.70 30.00 24.80 13.00 17.50 9.5 1. 5.7 0.02
CAB M08M08-C M08 M08 13.00 30.00 - - 17.50 9.6 2. - 0.02
CAB M08M10 M08 M10 13.00 40.00 33.40 18.00 20.20 15.0 1. 5.2 0.07
CAB M10M10-C M10 M10 18.00 35.00 - - 20.00 15.0 2. - 0.06
CAB M10M12 M10 M12 18.00 45.00 36.40 21.00 22.00 17.0 1. 2.5 0.09
CAB M12M12-C M12 M12 21.00 40.00 - - 22.00 17.0 2. - 0.08
CAB M12M16 M12 M16 21.00 50.00 42.50 29.00 25.00 25.0 1. 6.3 0.18
CAB M16M16-C M16 M16 29.00 40.00 - - 25.00 25.0 2. - 0.16
(1) Clamping wrench size

A 0.005 A 58-60 HRc
CAB M-SEM
FLEXFIT Shell Mill Holder DCONMS THSZMS DCONWS BD
Adaptation with Coolant Holes
DRVS
LSCMS LF LSCWS
Designation THSZMS DCONWS LF BD LSCWS DCONMS LSCMS DRVS (1) TQ_3 (2)
CAB M16 SEM 16 C M16 (3) 16.00 23.00 38.00 17.0 29.00 25.00 32.0 40
• For internal coolant through the holder, the related COOLANT SET should be ordered via Accessories (applicable to certain tools only)
• When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening
torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) Clamping wrench size
(2) Tool tightening torque Nxm (lbfxin)
(3) Tightening torque: 30 Nm Max

Spare Parts

Designation
CAB M16 SEM 16 C SR M3X10DIN912 SR M8X25DIN912
