Page 674 - ISCAR(MILLINGCATALOG 38_2021)

LPR AT3 Taper 58-60 HRc
CENTER ALIGNMENT DEVICES
ADJ BT SS LBX
Center Alignment Shanks and LB (1)
Bases with BT MAS-403
ADB Tapered Shanks for DCONWS BD_2 BD
Specially Tailored Toolholders
CRKS

Designation SS LPR LBX LB BD BD_2 DCONWS CRKS kg
ADJ BT40 D70 40 55.00 28.0 18.00 70.00 62.50 35.00 M16 1.56
ADJ BT50 D70 50 70.00 32.0 - 70.00 - 35.00 M24 4.34
• (1) Use 4 mm hex key for screw adjustment • Add B to the designation for coolant through flange option.

Spare Parts

Designation
ADJ BT SR M8X1X16 DIN916 SR M6X30 DIN912 OR 21X4N HW 4.0* ADJUST SPACER 9.5X5* HW 5.0*
* Optional, should be ordered separately

58-60 HRc
LS LPR LB
ADJ ST-ER
FINEFIT DIN 6499 ER Collet DCONMS CSI BD DF DCONNWS 0.2 1°
Chucks with Center Alignment DCONXWS
and Cylindrical Shanks
with a Clamping Flat

Designation DCONMS CSI DCONNWS (1) DCONXWS (2) LPR LB LS BD DF kg
ADJ ST25 D70 ER32 25.00 ER32 2.0 20.0 94.50 52.5 80.00 50.00 70.00 1.74
ADJ ST32 D70 ER32 32.00 ER32 2.0 20.0 94.50 52.5 80.00 50.00 70.00 1.91
• Radial adjustment 0.2 mm Angular adjustment 1°
(1) Minimum diameter
(2) Maximum diameter

Radial
Adjustment
Angular
Adjustment

684-688 715 682-684

Spare Parts
Designation
ADJ ST-ER ADJ ER32 NOSE

672 ISCAR
