USER GUIDE
Correct Wrong
Max Runout T.I.R. 0.003
4 7
Slim Design 4.5° ER, SC & SHRINK COLLETS
Powerful
Clamping Force Balancing Screw
Rigidity &
Stiffness by
Taper + Face
Contact
High Power
HSK Clamping
Short Insertion
Clearance
Long
Clamping
Area
1 Do not use Weldon type shanks.
2 Insert shank at least Lmin into the chuck.
3 In order to maintain a firm grip, shank’s surface
finish should have a roughness of at least N5. Preset
Balancing Screws Screw
Symmetrical Desing
Made from
Durable H13 Steel
