GROOVE-TURN MAHR/L-JHP-MC 20.0 B H 20.0 OAL 1.2 98.00 HBKW WF (adapter) WF (assembly) Left-hand shown • 20.0 Bar Max

HF
HBH
Holders with Bottom Inlets for
WF (shank)
High-Pressure Coolant Channels
Carrying MODULAR-GRIP
WF(assembly)=WF(shank)+WF(adapter)
Grooving and Turning Adapters
H
Designation
HBKW
(1)
HBH
WF
HF
B
OAL
6.00
MAHR/L 20-JHP-MC
14.0
10.0
MAHR/L 25-JHP-MC
19.0
25.0
25.0
98.00
25.0
-
5.0
• For CDX, refer to the adapters data.
(1) WF(shank)
For tools, see pages: HFPAD-JHP (562) • PCADRS/LS-JHP (317) • TGPAD-JHP (271) • CGPAD-JHP (282) • DGPAD-JHP (480) • HGPAD-JHP (267)
• PCADR/L-JHP (317) • TAGPAD-JHP (500) • CGPAD (281) • DGAD-B-D (479) • DGAD/HGAD (479) • HFPAD-3 (562) • HFPAD-4 (563) • HFPAD-5 (563) • HFPAD-6 (564)
• HGPAD (267) • PCADR/L (316) • SCLCR-PAD (55) • SDJCR-PAD (59) • SVJCR-PAD (67)
• SWAPR-PAD (73) • TGAD (498) • TGPAD (270)

Spare Parts

Designation
MAHR/L-JHP-MC SR M6X20-XT HW 5.0 SR M5-04451 T-20/5 SR M6X12DIN6912 OR 5X1N

MAHPR/L HF H
Holders for Perpendicularly
HBH
Mounted Adapters for LH OAL
all GRIP Systems
B
Right-hand shown
Designation H B HF OAL LH HBH
MAHPR/L 20 20.0 20.0 20.0 140.00 25.0 10.0
MAHPR/L 25 25.0 25.0 25.0 140.00 25.0 5.0
MAHPR/L 32 32.0 32.0 32.0 150.00 25.0 -
For tools, see pages: CGPAD (281) • DGAD-B-D (479) • DGAD/HGAD (479) • HFPAD-3 (562) • HFPAD-4 (563) • HFPAD-5 (563) • HFPAD-6 (564)
• HGPAD (267) • PCADR/L (316) • SCLCR-PAD (55) • SDJCR-PAD (59) • SVJCR-PAD (67) • SWAPR-PAD (73) • TGAD (498) • TGPAD (270)

Spare Parts

Designation
MAHPR/L SR M5-04451 T-20/5 SR 14-519 SR M6X20-XT (a) HW 5.0 SR M6X6DIN551 14H/22H
(a) For CGPAD, HGPAD, TGPAD and HFPAD adapters. Supplied with the tools.

280 ISCAR
