GROOVE-TURN GHDR/L-JHP (short pocket) 2.80 (2) CWX (3 inlet ports) H CDX (4) CWN-CWX 20.0 LH G 1/8"-28 typx2 29.0 H B WB 18.80 WB 20.0
HF
Grooving and Turning Tools
20 mm shank tools
with Channels for High-Pressure
OAL
CDX
Coolant
Bar Max
WF
Right-hand shown
B
(3)
Designation
WF
HF
OAL
LH
CWN
20.0
2.40
9.00
4.00
120.00
GHDR/L 20-3-JHP
GHDR/L 25-3-JHP
2.80
4.00
44.0
140.00
23.80
25.0
2.40
9.00
25.0
25.0
GHDR/L 20-4-JHP
5.00
GHDR/L 25-4-JHP
25.0
10.00
5.00
25.0
3.20
25.0
23.40
140.00
45.0
4.00
25.0
4.20
5.00
GHDR/L 25-5-JHP
12.00
22.90
25.0
46.0
25.0
140.00
6.40
25.0
150.00
21.80
50.0
GHDR/L 25-P8-JHP (1) 4.00 10.00 20.0 10.00 20.0 120.00 29.0 18.40 3.20 20.0
7.00
25.0
6.50
16.50
25.0
• For using TIP and GPV inserts, toolholder seat needs to be modified according to insert profile to ensure clearance
• For user guide and accessories see pages 419-436
(1) Used with GIMF, GIMY, GIPY, GIMM, GITM, GPV, GIMY-F, GIMM 8CC,GIMT,GIMN,GITM (full radius), GIMY (full radius) inserts.
(2) Minimum cutting width
(3) Maximum cutting width
(4) Cutting depth maximum
For inserts, see pages: GIA-K (W=3-6) (298) • GIF (297) • GIF (full radius) (298) • GIF-E (W=4-6 full radius) (294) • GIF-E (W=4-6) (292)
• GIM-C (521) • GIM-J (522) • GIM-J-RA/LA (522) • GIM-UT (524) • GIM-UT-RA/LA (524) • GIM-W (523) • GIM-W-RA/LA (523) • GIMF (288)
• GIMM 8CC (583) • GIMN (289) • GIMT (287) • GIMY (288) • GIMY (full radius) (290) • GIMY-F (291) • GIP (297) • GIP (full radius) (296)
• GIP-E (293) • GIP-E (full radius) (294) • GIP-UN (303) • GIPA (full radius W=3-6) (301) • GIPA (W=3-6) (300) • GIPM-A46 / GIP-1250 (375)
• GIPY (300) • GITM (299) • GITM (full radius) (299) • GPV (304) • TIP-MT (647) • TIP-P-BSPT (674) • TIP-P-BSW (668) • TIP-P-ISO (658)
• TIP-P-NPT (671) • TIP-P-UN (664) • TIP-WT (641)
Flow Rate vs. Pressure GHDR...-JHP
G 1/8”-28 Adaptation Nipple
70 Bar 100 Bar 140 Bar Hose
Flow Rate Flow Rate Flow Rate
Designation (liters/min) (liters/min) (liters/min)
GHDR/L 20-3-JHP 5-7 7-9 9-11
GHDR/L 20-4-JHP 6-8 10-12 12-14
GHDR/L 25-3-JHP 6-8 8-10 10-12
GHDR/L 25-4-JHP 10-12 14-16 16-18
GHDR/L 25-5-JHP 13-16 19-21 22-24 PLUG G 1/8”-28
Copper Seal Washer 1/8” Key: HW 5.0

Spare Parts
Designation
GHDR/L 20-3-JHP SR M5X16 DIN912 HW 4.0 (a) PLG G1/8 TL360 HW 5.0
GHDR/L 25-3-JHP SR M5X20DIN912 HW 4.0 (a) PLG 1/8ISO1179 HW 5.0
GHDR/L 20-4-JHP SR M6X16 DIN912 PLG G1/8 TL360 HW 5.0
GHDR/L 25-4-JHP SR M6X20 DIN912 PLG 1/8ISO1179 HW 5.0
GHDR/L 25-5-JHP SR M6X20 DIN912 PLG 1/8ISO1179 HW 5.0
GHDR/L 25-P8-JHP SR M6X20 DIN912 PLG 1/8ISO1179 HW 5.0
(a) For optional key with limited tightening torque see page 428
