PICCO-620-N (Face                                     OAL

          Grooving along Shaft)                                                   DAXN
          Inserts with Internal Coolant
                                                 a
          Channel for Grooving along
          Shaft Dmin 6 mm                                 CDX              DCONMS

                                                  CW
                                                           LU                                                         FACE GROOVING
                                                          Dimensions                                 Recommended
                                                                                                     Machining Data

                                                                                                  IC908  f face-groove
           Designation         DAXN (1)  CW       CDX    DCONMS       a        LU       OAL            (mm/rev)
           PICCO R 620.1006-20N  6.0     1.00     2.00     6.05      5.20      19.0     41.00    •      0.01-0.04
           PICCO R 620.1506-20N  6.0     1.50     3.00     6.05      5.20      19.0     41.00    •      0.01-0.05
           PICCO R 620.2006-20N  6.0     2.00     4.00     6.05      5.20      19.0     41.00    •      0.02-0.06
           PICCO R 620.2506-20N  6.0     2.50     5.00     6.05      5.20      19.0     41.00    •      0.02-0.06
           PICCO R 620.3006-20N  6.0     3.00     6.00     6.05      5.20      19.0     41.00    •      0.02-0.06
          •  Only right-hand inserts are available as standard, left-hand inserts on request    •  All carbide inserts are with sharp corners
          •   Solid tools are suitable for PICCO-N / PICCO ACE-N type holders only   •  For detailed cutting data, see page 604
          (1)  Minimum axial grooving diameter

























          PICCO-620                                              OAL
          (Groove Along Shaft)                                          DCONMS
          Inserts for Grooving Along                           CDX             DAXN
          a Shaft Dmin 6 mm                             a
                                                              OHN
                                                          CW
                                                                                                   Right-hand shown
                                                                                                      Recommended
                                                           Dimensions
                                                                                                      Machining Data

                                                                                                   IC1008  f face-groove
           Designation         DAXN (1)   CW      CDX      DCONMS      a       OHN (2)   OAL            (mm/rev)
           PICCO R 620.1006-20   6.0      1.00     2.00      6.00     5.20      20.0     35.00    •     0.01-0.04
           PICCO R 620.1506-20   6.0      1.50     3.00      6.00     5.20      20.0     35.00    •     0.01-0.05
           PICCO R 620.2006-20   6.0      2.00     4.00      6.00     5.20      20.0     35.00    •     0.02-0.06
           PICCO R 620.2506-20   6.0      2.50     5.00      6.00     5.20      20.0     35.00    •     0.02-0.06
           PICCO R 620.3006-20   6.0      3.00     6.00      6.00     5.20      20.0     35.00    •     0.02-0.06
          •  Only right-hand inserts are available as standard, left-hand inserts on request    •  All carbide inserts are with sharp corners
          •   For detailed cutting data, see page 604
          (1)  Minimum axial grooving diameter
          (2)  Minimum overhang
