TOOL BLOCKS UBHCR/L H HTPRM B OAH OAL OAL OAW HTPRM Right-hand shown

Holders for Grooving, Turning
OAH H
and Parting Blades
B

Designation
OAW
UBHCR/L 20-26
20.0
UBHCR/L 25-32
130.00
25.0
40.00
46.0
BKU 176 307 SR M6X16 DIN912
SPRING PLUNGER M6X14X3.5
25.0
32.0
HW 5.0
32.0
32.0
BKU 176 307 SR M6X16 DIN912
HW 5.0
SPRING PLUNGER M6X14X3.5
46.0
47.00
130.00
UBHCR/L 32-32
32.0
• Choose blade by HTPRM dimension 26.0 20.0 42.0 35.60 100.00 BKU 176 307 SR M6X16 DIN912 HW 5.0 SPRING PLUNGER M6X14X3.5
For tools, see pages: CGHN-D (283) • CGHN-DG (283) • CGHN-S (282) • CGHR/L-P8DG (284) • DGFH (268) • DGFHR/L (468) • DGFHR/L-B-D..(R/L) (470)
• HFFA (557) • HFFH (557) • HFFR/L-T (564) • HGFH (268) • SGFFA (587) • SGFFH (588) • TGFH/R/L (332) • TGFHL-TR (505) • TGFHR/L (495) • TGHN-D (271)
• TGHN-S (271) • TNFFA-IQ (584) • TNFFH-IQ (583)

h2 Ref. (a)
SGTBF HTPRM H OAH
Perpendicular Blocks for WTHPRM
Parting and Grooving Blades
OAW B
LSCMS
OAL
Designation H B HTPRM OAL LSCMS OAW OAH WTHPRM
SGTBF 25-A 25.0 25.0 32.0 102.00 80.00 48.00 48.0 5.50 SR M6X40 DIN912 HW 5.0
SGTBF 32-A 32.0 32.0 32.0 116.00 100.00 48.00 48.0 5.50 SR M6X40 DIN912 HW 5.0
• (a) h2 Ref. as defined for SELF-GRIP face grooving blades • Choose blade by HTPRM dimension
For tools, see pages: DGFH (268) • DGFHR/L (468) • DGFHR/L-B-D..(R/L) (470) • HFFH (557) • HFFR/L-T (564) • HGFH (268) • SGFFA (587) • SGFFH (588)
• TGFH/R/L (332) • TGFHR/L (495) • TNFFA-IQ (584) • TNFFH-IQ (583)

618 ISCAR
