Page 163 - DC_SWISS(Catalogue_TM_ES-EN)

~ DIN 371 (d2 h6)
PM
UNC ASME B1.1 ~ DIN 376 (d2 h6)

Z Z370VS 3 Z470VS 3
S

Z370VS-3 VS
R45 CLASSIC
14 15 21 22 23
24 51 61 94

Z470VS 3 VS
R45 CLASSIC

Z370VS-3 VS
R45 SYNCHRO
13 14 15 21 22
23 24 51 52 < 3 x D < 3 x D

Z470VS-3 VS
R45 SYNCHRO

C C
a
d 2
2.5 x P 2.5 x P
d 1
l
2
l
3 l P
1
Ø’’ d 1 P d 1 l 1 l 2 l 3 d h6 a ID ID
2
UNC TPI mm mm mm mm mm mm
6 32 3.5 56 6.5 20 4.5(h9) 3 3 2.75 l 166123
8 32 4.16 63 7.5 21 4.5(h9) 3.4 3 3.4 l 166124
10 24 4.82 70 9 25 6 4.9 3 3.8 l 166125
1/4 20 6.35 80 11 30 * 6 * 4.9 3 5.1 l 166126
5/16 18 7.93 90 12.5 35 8 6.2 3 6.5 l 166127
3/8 16 9.52 100 14 39 10 8 3 8 l 166128
7/16 14 11.11 100 14 8 6.2 3 9.3 l 166129
1/2 13 12.7 110 14 * 10 * 8 4 10.8 l 166130
5/8 11 15.87 110 18 12 9 4 13.6 l 166131
3/4 10 19.05 125 21 14 11 4 16.6 l 166132
1 8 25.4 160 27 16 12 4 22.3 l 175703

* Norme DC / * DC Norm/ * Norma DC

Ø’’ d 1 P d 1 l 1 l 2 l 3 d h6 a UNJC ID
2
UNC TPI mm mm mm mm mm mm
4 40 2.84 56 5.5 18 3.5(h9) 2.7 3 2.3 l 165114
6 32 3.5 56 6.5 20 4 (h9) 3 3 2.8 l 165115
8 32 4.16 63 7.5 21 4.5(h9) 3.4 3 3.45 l 165116
1/4 20 6.35 80 11 30 * 6 * 4.9 3 5.2 l 165117
5/16 18 7.93 90 12.5 35 8 6.2 3 6.7 l 165118

* Norme DC / * DC Norm/ * Norma DC
