UNF ASME B1.1 PM ~ DIN 371

SA390 3

SA390-3 16 53
R10

< 1.5 x D

< 1.5 x D

C
2.5 x P

P

Ø’’ d 1 P d 1 l 1 l 2 d 2 a UNJF ID
UNF TPI mm mm mm mm mm
10 32 4.82 70 15 6 4.9 3 4.15 l 149687
1/4 28 6.35 80 20 7 5.5 3 5.55 l 149715
5/16 24 7.93 90 25 8 6.2 3 7 l 149728
3/8 24 9.52 100 30 10 8 3 8.6 l 149745
