ASME B1.1 VHM
UNC, UNF ASME B1.2 CAR

DN01 GO DN02 NO•GO DN01 GO DN02 NO•GO

d 2

l
1

l
2

d 1

P

Ø d 1 P Ø d 1 l 1 l GO d 2 ID ID ID ID
2
UNC TPI mm mm mm mm
1 64 1.854 24 6.35 6 l 191577 l 191580 l 191583 l 191586
2 54 2.184 24 6.35 6 l 191578 l 191581 l 191584 l 191587
3 48 2.515 24 6.35 6 l 191579 l 191582 l 191585 l 191588

Ø d 1 P Ø d 1 l 1 l GO d 2 ID ID ID ID
2
UNF TPI mm mm mm mm
0 80 1.524 24 4.76 6 l 191637 l 191641 l 191645 l 191649
1 72 1.854 24 4.76 6 l 191638 l 191642 l 191646 l 191650
2 64 2.184 24 4.76 6 l 191639 l 191643 l 191647 l 191651
3 56 2.515 24 4.76 6 l 191640 l 191644 l 191648 l 191652

All nano thread plug gauges are SCS-certified and the paid certificate is available on request.
