P. 70
HSSE DIN 376
M ISO DIN 13
N420«4 N420«4 LH N420V«4 LH
N
62 63 72 73 74
N420-4
81 91
62 63 72 73 74
N420-4 LH LH
81 91
N420V-4 LH V LH 11 12 31 32
a B B B
d 2
4 x P 4 x P 4 x P
d 1
l 2
l
1 P
Ø d 1 P l 1 l 2 d 2 a ID ID ID
M mm mm mm mm mm
8 1.25 90 20 6 4.9 3 ∆ 6.8 l 102193 l 102198 l 142621
10 1.5 100 22 7 5.5 3 8.5 l 102059 l 102064 l 143287
12 1.75 110 24 9 7 3 10.2 l 102070 l 102040 l 146583
14 2 110 28 11 9 3 12 l 102084 l 146563
16 2 110 30 12 9 3 14 l 102093 l 143108
20 2.5 140 36 16 12 3 17.5 l 102103 l 145579
24 3 160 39 18 14.5 4 21 l 111493 l 145578
∆
= 6.70
67
