≤ Ø 2.8 > Ø 2.8
PM HSSE DIN 371
M ISO DIN 13

N360«5 N360V«5 N361«3 N362V«3

N

N360-5 63 72 73 74 81 91
R40

N360V-5 V 11 12 32
R40

61 63 71 72 73 74
N361-3
R40 81 91

< 2.5 x D < 2.5 x D < 2.5 x D < 2.5 x D

N362V-3 V 11 12 32
R40

C C
a
d 2
2.5 x P 2.5 x P
d 1
l
2
l
3 l P
1
Ø d 1 P l 1 l 2 l 3 d 2 a ID ID ID ID
M mm mm mm mm mm mm
2 0.4 45 7 2.8 2.1 2 1.6 l 158079 l 150058
3 0.5 56 5.5 18 3.5 2.7 3 2.5 l 104809 l 142646 l 101735
4 0.7 63 7.5 21 4.5 3.4 3 3.3 l 104810 l 142647 l 101736 l 101741
5 0.8 70 9 25 6 4.9 3 4.2 l 104811 l 142648 l 101737 l 101742
6 1 80 11 30 6 4.9 3 5 l 104812 l 142649 l 101738 l 101743
8 1.25 90 12.5 35 8 6.2 3 6.8 l 104813 l 142650 l 101739 l 101744
10 1.5 100 14 39 10 8 3 8.5 l 104814 l 124899 l 101734 l 101740
