Page 82 - DC_SWISS(Catalogue_TM_ES-EN)
P. 82
HSSE DIN 376
M ISO DIN 13
N460«3 N460«3 N460V«3
N
N460-3 63 72 73 74 81 91
R40
N460V-3 V 11 12 32
R40
< 2.5 x D < 2.5 x D < 2.5 x D
a C C C
d 2
2.5 x P 2.5 x P 2.5 x P
d 1
l 2
l
1 P
Ø d 1 P l 1 l 2 d 2 a 6H ID ID 6H ID 6H
M mm mm mm mm mm + mm + mm
12 1.75 110 14 9 7 3 10.2 124987 l 102363 0.066 l 142532 0.066
16 2 110 18 12 9 3 14 l 102379 0.072 l 144956 0.072
6H 6H
+0.1 mm +0.1 mm
Ø d 1 P l 1 l 2 d 2 a 6H ID ID
M mm mm mm mm mm +0.1
12 1.75 110 14 9 7 3 10.3 l 102360 l 125044
16 2 110 18 12 9 3 14.1 l 102377 l 145311
79
