a e
n
v f
a p
d 1
v c
f z
Q
Application Material [mm] z [m/min] [mm] [mm] [mm] [min ] -1 [mm/min] [cm /min]
3
Steel 6.00 4 85 0.315 0.240 3.600 4510 5683 4.9
850 - 1100 N/mm² 8.00 4 85 0.420 0.320 4.800 3380 5678 8.7
10.00 4 85 0.525 0.400 6.000 2705 5681 13.6
12.00 4 85 0.630 0.480 7.200 2255 5683 19.6
16.00 4 85 0.695 0.560 9.600 1690 4698 25.3
Steel 6.00 4 80 0.270 0.240 3.600 4245 4585 4.0
1100 - 1300 N/mm² 8.00 4 80 0.355 0.320 4.800 3185 4523 6.9
10.00 4 80 0.445 0.400 6.000 2545 4530 10.9
12.00 4 80 0.535 0.480 7.200 2120 4537 15.7
16.00 4 80 0.590 0.560 9.600 1590 3752 20.2
Steel 6.00 4 75 0.245 0.220 3.600 3980 3900 3.1
1300 - 1500 N/mm² 8.00 4 75 0.330 0.290 4.800 2985 3940 5.5
10.00 4 75 0.410 0.360 6.000 2385 3911 8.4
12.00 4 75 0.490 0.430 7.200 1990 3900 12.1
16.00 4 75 0.540 0.500 9.600 1490 3218 15.4

Hardened tool steel 6.00 4 70 0.190 0.190 3.600 3715 2823 1.9
48 - 52 HRC 8.00 4 70 0.250 0.260 4.800 2785 2785 3.5
10.00 4 70 0.315 0.320 6.000 2230 2810 5.4
12.00 4 70 0.380 0.380 7.200 1855 2820 7.7
16.00 4 70 0.415 0.450 9.600 1395 2316 10.0

Hardened tool steel 6.00 4 65 0.140 0.170 3.600 3450 1932 1.2
52 - 56 HRC 8.00 4 65 0.190 0.220 4.800 2585 1965 2.1
10.00 4 65 0.235 0.280 6.000 2070 1946 3.3
12.00 4 65 0.285 0.340 7.200 1725 1967 4.8
16.00 4 65 0.315 0.390 9.600 1295 1632 6.1

Hardened tool steel 6.00 4 55 0.090 0.160 3.600 2920 1051 0.6
56 - 60 HRC 8.00 4 55 0.120 0.210 4.800 2190 1051 1.1
10.00 4 55 0.145 0.260 6.000 1750 1015 1.6
12.00 4 55 0.175 0.310 7.200 1460 1022 2.3
16.00 4 55 0.195 0.360 9.600 1095 854 3.0
