Page 610 - 21-036 APPLITEC catalogue.indb

a p
a e
n
d 1
v c
f z
v f
Q
Application Material [mm] z [m/min] [mm] [mm] [mm] [min -1 ] [mm/min] [cm 3 /min]
Wrought aluminium 12.00 3 500 0.222 18.000 5.400 13265 8835 858.7
Construction aluminium 16.00 3 500 0.237 24.000 7.200 9945 7065 1220.8
20.00 3 500 0.278 30.000 9.000 7960 6627 1789.2
Unalloyed copper 12.00 3 375 0.166 18.000 5.400 9945 4941 480.2
16.00 3 375 0.177 24.000 7.200 7460 3953 683.1
20.00 3 375 0.207 30.000 9.000 5970 3707 1001.0

Thermoplastics 12.00 3 500 0.266 18.000 5.400 13265 10601 1030.5
16.00 3 500 0.284 24.000 7.200 9945 8478 1465.0
20.00 3 500 0.333 30.000 9.000 7960 7952 2147.0

Cast aluminium 12.00 3 400 0.178 18.000 5.400 10610 5653 549.5
16.00 3 400 0.189 24.000 7.200 7960 4524 781.7
20.00 3 400 0.222 30.000 9.000 6365 4239 1144.6

Wrought aluminium 12.00 3 400 0.128 18.000 12.000 10610 4063 877.6
Construction aluminium 16.00 3 400 0.136 24.000 16.000 7960 3252 1248.6
20.00 3 400 0.160 30.000 20.000 6365 3047 1828.1

Unalloyed copper 12.00 3 300 0.095 18.000 12.000 7960 2274 491.2
16.00 3 300 0.102 24.000 16.000 5970 1819 698.5
20.00 3 300 0.119 30.000 20.000 4775 1705 1023.0

Thermoplastics 12.00 3 400 0.153 18.000 12.000 10610 4876 1053.2
16.00 3 400 0.163 24.000 16.000 7960 3902 1498.3
20.00 3 400 0.191 30.000 20.000 6365 3656 2193.7

Cast aluminium 12.00 3 320 0.102 18.000 12.000 8490 2601 561.8
16.00 3 320 0.109 24.000 16.000 6365 2080 798.7
20.00 3 320 0.128 30.000 20.000 5095 1951 1170.7
