Page 195 - GARR_TOOL(CATALOG_INT)
P. 195
TOLERANCES Series H-45
d1 +.000" –.002" (+.000mm –.050mm)
d2 h6 HIGH FEED END MILLS
r +.001" –.001" (+.025 –.025mm)
314
Corner Radius - AlTiN Coated END MILLS HIGH PERFORMANCE
Eckenradius - AlTiN-Beschichtet
Ángulo Redondeado - Recubrimiento de AlTiN
Rayon de Coin - Revêtement AlTiN
Torico - Rivestimento in AlTiN
圆角半径 - 涂层
圆角半径 - AlTiN 涂层
Solid submicron grain carbide end mill - center cutting
For light axial / radial depths of cut
Recommended for die mold applications 70 6
Rigid work holding, machine stability and part integrity are critical!
* - tool has 3° blend angle to shank
* - tool has reduced diameter shank
d1 † d2 l1 l2 r l3 d3
EDP# Diameter Shank Overall Flute Corner Reach Neck
Decimal Metric Diameter Length Length Radius Length Diameter
Hochleistungs- Vollhartmetallfräser aus Feinkornhartmetall - Zentrumsschnitt
Hochleistungswerkzeug für die Bearbeitung von Teilen mit kleinen axialen Schnittiefen 48300 .1181 3.000 6.0 65 3 0.75 15.0 2.80
Empfohlen für Werkzeuganwendungen 48305 .1250 1/8" 3.175 1/8" 3" 1/8" .015" - -
Gute Werkstückspannung, Machschinenstabilität und Teileintegration sind 48310 .1250 1/8" 3.175 1/8" 3" 1/8" .030" - -
entscheidend ! 48315 .1250 1/8" 3.175 3/16" 2-1/2" 1/8" .010" 3/4" .115"
48320 .1250 1/8" 3.175 3/16" 2-1/2" 1/8" .015" 3/4" .115"
* - Das Werkzeug hat einen konischen Hals von 3°
* - Das Werkzeug hat einen reduzierten Schaftdurchmesser 48325 .1250 1/8" 3.175 3/16" 2-1/2" 1/8" .020" 3/4" .115"
* 48330 .1250 1/8" 3.175 3/16" 3" 1/8" .030" * -
48335 .1575 4.000 6.0 65 4 1.00 20.0 3.70
Fresa de submicrograno sólido carburo de alto rendimiento - corte centrado 48340 .1875 3/16" 4.763 3/16" 3" 3/16" .015" - -
Herramienta de alto rendimiento para uso en profundidades axiales ligeras de corte 48345 .1875 3/16" 4.763 3/16" 3" 3/16" .030" - -
Recomendado para aplicaciones de Moldes 48350 .1875 3/16" 4.763 3/16" 3" 3/16" .060" - -
La sujección firme del útil, la estabilidad de la máquina y la integridad de 48355 .1875 3/16" 4.763 1/4" 2-1/2" 3/16" .020" 7/8" .175"
las piezas son cruciales
48360 .1875 3/16" 4.763 1/4" 2-1/2" 3/16" .030" 7/8" .175"
* - la herramienta tiene un ángulo de mezcla de 3 ° con el vástago 48365 .1875 3/16" 4.763 1/4" 2-1/2" 3/16" .060" 7/8" .175"
* - la herramienta tiene un vástago de diámetro reducido 48370 .1875 3/16" 4.763 1/4" 4" 3/16" .020" 1-1/2" .175"
48375 .1875 3/16" 4.763 1/4" 4" 3/16" .030" 1-1/2" .175" 35 6
* 48380 .1875 3/16" 4.763 1/4" 4" 3/16" .030" * -
Fraises carbure submicrograin - coupe au centre * 48385 .1969 5.000 6.0 100 5 1.20 * 10.0 5.00
Outil haute performance pour un usinage avec des petites profondeurs de coupe axiales 48390 .2362 6.000 6.0 100 6 1.50 30.0 5.70
Recommandé pour les applications de matrices 48395 .2500 1/4" 6.350 1/4" 3" 1/4" .015" - -
Le serrage et la stabilite de la piece, la rigidite de la machine et l’atatchment
de l’outil sont tres importantes 48400 .2500 1/4" 6.350 1/4" 3" 1/4" .030" - -
48405 .2500 1/4" 6.350 1/4" 3" 1/4" .060" - -
* - L'outil a un angle de dégagement de 3° sur la queue * 48410 .2756 7.000 6.0 100 7 1.50 * -
* - L'outil a un diamètre de queue réduit 48415 .3125 5/16" 7.938 5/16" 2-1/2" 5/16" .020" - -
48420 .3125 5/16" 7.938 5/16" 3" 5/16" .078" 1-5/8" .300"
48425 .3125 5/16" 7.938 5/16" 3" 5/16" .094" 1-5/8" .300" MATERIAL HARDNESS (Rc)
Fresa sub-micrograno metallo duro - taglio al centro 48430 .3150 8.000 8.0 75 8 2.00 - -
Utensile ad alte prestazioni per piccole profondità di taglio 48435 .3150 8.000 8.0 100 8 2.00 40.0 7.70
Consigliato per le applicazioni Die Mold
Serraggio rigido, macchina stabile e ottimo bloccaggio del pezzo sono necessari! 48440 .3750 3/8" 9.525 3/8" 3" 3/8" .015" - -
48445 .3750 3/8" 9.525 3/8" 3" 3/8" .030" - -
* - utensile con 3° di inclinazione rispetto al gambo 48450 .3750 3/8" 9.525 3/8" 3" 3/8" .060" - -
* - utensile con diametro ridotto del gambo 48455 .3750 3/8" 9.525 3/8" 3" 3/8" .094" 2.00" .365"
48460 .3750 3/8" 9.525 3/8" 4" 3/8" .030" 2-1/2" .365"
48465 .3750 3/8" 9.525 3/8" 4" 3/8" .094" 2-1/2" .365"
48470 .3937 10.000 10.0 100 10 2.00 50.0 9.70
超细晶粒整体硬质合金立铣刀 - 中心切削 48475 .4724 12.000 12.0 100 12 3.00 60.0 11.70
适用于轴向小切深加工的高性能铣刀
推薦用於模具應用 48480 .5000 1/2" 12.700 1/2" 3" 1/2" .015" - -
高刚性工件夹持、机床稳定性以及零件的牢固性是至关重要的因素！ 48485 .5000 1/2" 12.700 1/2" 3" 1/2" .030" - - 0
48490 .5000 1/2" 12.700 1/2" 3" 1/2" .060" - - 6
* - 部分型号柄部有3°过渡角 48495 .5000 1/2" 12.700 1/2" 3" 1/2" .125" - -
* - 部分型号柄径小于刃径 48500 .5000 1/2" 12.700 1/2" 4" 1/2" .125" - -
+1 989-463-6171 fax +1 989-463-3609 195
