Series 255RA, 855RA (continued)

.3150" - 1.000"
HIGH PERFORMANCE END MILLS EDP# Decimal Diameter Metric Diameter Overall Length Corner
(8.000mm - 25.400mm)

r
d1
†
l1
l2
d2
Shank
Flute
Length
Radius
83987
8.000
.3150
12
50
8.0
1.00
83997
65
84000
0.30
.3150
8.000
22
8.0
.3150
65
8.000
0.50
84007 .3150 8.000 8.0 50 12 0.50
8.0
22
84017 .3150 8.000 8.0 65 22 1.00
84027 .3150 8.000 8.0 65 22 1.50
84087 .3750 3/8" 9.525 3/8" 2" 1/2" .020"
84097 .3750 3/8" 9.525 3/8" 2" 1/2" .030"
84100 .3750 3/8" 9.525 3/8" 2-1/2" 7/8" .010"
84107 .3750 3/8" 9.525 3/8" 2-1/2" 7/8" .020"
84117 .3750 3/8" 9.525 3/8" 2-1/2" 7/8" .030"
70 84137 .3750 3/8" 9.525 3/8" 2-1/2" 7/8" .060"
6
84147 .3750 3/8" 9.525 3/8" 3" 1-1/4" .030"
84167 .3937 10.000 10.0 70 22 0.50
84177 .3937 10.000 10.0 70 22 1.00
84257 .4724 12.000 12.0 75 32 0.30
84267 .4724 12.000 12.0 75 32 0.50
84277 .4724 12.000 12.0 75 32 1.00
84287 .4724 12.000 12.0 75 32 1.50
84307 .5000 1/2" 12.700 1/2" 3" 1-1/4" .010"
84317 .5000 1/2" 12.700 1/2" 3" 1-1/4" .020"
84327 .5000 1/2" 12.700 1/2" 3" 1-1/4" .030"
84337 .5000 1/2" 12.700 1/2" 3" 1-1/4" .060"
84357 .5000 1/2" 12.700 1/2" 3" 1-1/4" .120"
84367 .5000 1/2" 12.700 1/2" 4" 2" .030"
84377 .5000 1/2" 12.700 1/2" 4" 2" .060"
84397 .5000 1/2" 12.700 1/2" 4" 2" .120"
84467 .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .015"
84487 .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .030"
84497 .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .060"
84507 .6250 5/8" 15.875 5/8" 3-1/2" 1-1/4" .120"
84567 .6299 16.000 16.0 88 32 1.00
35 84577 .6299 16.000 16.0 88 32 2.00
6
84587 .6299 16.000 16.0 150 65 1.00
84597 .6299 16.000 16.0 150 65 2.00
84667 .7500 3/4" 19.050 3/4" 4" 1-1/2" .015"
MATERIAL HARDNESS (Rc) 84700 .7874 3/4" 19.050 3/4" 100 1-1/2" .120"
1-1/2"
19.050
4"
3/4"
.7500
84687
3/4"
.030"
19.050
1-1/2"
4"
3/4"
.060"
3/4"
.7500
84697
4"
.7500
.030"
3/4"
19.050
.7500
5"
84707
2"
3/4"
.7500
2"
19.050
5"
84717
3/4"
3/4"
.060"
5"
3/4"
84747
2"
.7500
.120"
19.050
3/4"
5"
3/4"
.190"
2"
3/4"
84757
.7500
19.050
38
84767
20.000
20.0
1.00
3.00
38
84777
84887
100
25.000
25.0
38
1.00
.9843
38
.9843
100
25.000
25.0
3.00
84897
1.000
25.400
84957 .7874 1" 20.000 20.0 100 1-1/2" .015"
4"
1"
84967 1.000 1" 25.400 1" 4" 1-1/2" .030"
84970 1.000 1" 25.400 1" 4" 1-1/2" .060"
84977 1.000 1" 25.400 1" 4" 1-1/2" .120"
84987 1.000 1" 25.400 1" 5" 2" .030"
84990 1.000 1" 25.400 1" 5" 2" .060"
0 84997 1.000 1" 25.400 1" 5" 2" .120"
6
85007 1.000 1" 25.400 1" 5" 2" .190"
