USER GUIDE
ENDMILLS • SOLID CARBIDE • MULTI-MASTER
Indexable Solid Carbide Milling Heads
Table of Contents
Type Helix Angle No. of Flutes Diameter Range Remarks Page
MM EPG — 1 8 Engraving 50
MM FM — 6 12-25 Face Mill 61
MM EB 30º 2, 4 5-25 71
MM EBC 45º 4 8-20 Ball Nose Milling 72
MM EOB — 4 8,10,12,16 Oval-Shaped (Barrel) 61
MM ELB — 4 8,10,12,16 Lens-Shaped (Barrel) 61
MM HCR — 2 8-16 Ball Nose for 70
MM HRF General Finishing E
MM HBR — 2 10-25.4 Center Cutting, 240° 71 E
Spherical Cutting Profile
MM HT — 2 10-20 Torodial 69 E
MM FF — 2 10-20 Feed Mill 67 E
MM EFF — 4,6 8-25.4 Feed Mill 68
MM ETR 30˚ 6 8-16 Torodial 69
MM HR — 2 8-20
MM ER 4 8-12.7 Corner Rounding 49 E
Chamfering, Countersinking and
MM HCD — 2 8-20 45 E
Spot Drilling for DIN 74 Screw
8-25
MM ECF — 4, 6 Chamfering and Countersinking 46
10-25
MM ECS — 2 1.07-6.41 Centering Drills (DIN 332) 51
MM ECDF — 2 8-20 Flat Bottom Drill Heads 52
