Page 512 - ISCAR(MILLINGCATALOG 38_2021)

MILLING INSERTS SEKT-AF-R Dimensions S BS 45° Tough 1 Hard Machining Data
L
Super Positive Square Milling
Inserts for 45° Finishing
and Medium Machining
APMX
of Soft Materials
Recommended

ap
fz
(mm/t)
Designation
(mm)
S
BS
L
6.40
SEKT 1204AFR-HM
• For cutting speed recommendations, see pages 542-547
For tools, see pages: F45ST (225) 5.16 2.16 APMX 12.90 • IC28 • IC328 • IC928 • IC250 • IC950 • IC30N • IC520M 2.00-6.00 0.10-0.15

SEMT 1204AF-R-HS L/IC
Square Milling Inserts with
Chip Splitting Serrated Cutting
Edge for 45° Roughing 45° APMX
BS
S
Dimensions Tough 1 Hard Recommended Machining Data

IC328 IC928 ap fz
Designation L S BS APMX (mm) (mm/t)
SEMT 1204AF-R-HS 12.65 4.76 2.26 6.00 • • 2.00-6.00 0.20-0.30
• For cutting speed recommendations, see pages 542-547
For tools, see pages: F45ST (225)

SEHW-AFTN L
Precision Ground Sharp
Cutting Edge Milling
Inserts for General Use
45° APMX
BS
S
Dimensions Tough 1 Hard Recommended Machining Data

IC328 IC520M ap fz
Designation L S BS APMX (mm) (mm/t)
SEHW 1204AFTN 12.70 4.76 2.20 6.50 • • 2.00-6.00 0.12-0.20
• For cutting speed recommendations, see pages 542-547
For tools, see pages: F45ST (225)

SEKT-AFTN IC=L
Square Screw-Clamped Inserts
for Medium Machining
APMX
45°
S BS

Dimensions Recommended Machining Data

IC328 ap fz
Designation L S BS APMX (mm) (mm/t)
SEKT 12T3AFTN 13.15 3.70 2.18 6.50 • 2.00-6.00 0.12-0.20
• For cutting speed recommendations, see pages 542-547
For tools, see pages: F45ST (225)
