ONHU 0505-W IC
Double-Sided Octagonal Wiper A
22.5° 45°
Inserts with 4 or 8 Cutting Edges
APMX
BS A S

Dimensions Tough 1 Hard Recommended Machining Data MILLING INSERTS

IC808 IC810 ap fz
Designation IC APMX S BS (mm) (mm/t)
ONHU 0505AN-N-W (1) 13.00 2.00 4.90 4.70 • 0.50-2.00 0.15-0.30
ONHU 0505AN-R-W (2) 13.00 2.00 4.90 4.50 • • 0.50-2.00 0.15-0.30
• To be used with ONMU/ONHU 05 inserts • For cutting speed recommendations, see pages 542-547
(1) Wiper insert with 4 right- and 4 left-hand cutting edges
(2) Wiper insert with 8 right-hand cutting edges
For tools, see pages: SOE45 8/16 (38) • SOF45 (222)

OXMT 0507R08-FF OXMT 050705-R-HP
OXMT 0507 IC L
Octagonal High Feed 45° Inserts
IC
45°
15° APMX
BS L APMX S BS

Dimensions Tough 1 Hard Recommended Machining Data

IC830 IC808 ap fz
Designation APMX IC BS S L (mm) (mm/t)
OXMT 0507R08-FF (1) 1.20 14.50 0.80 7.00 5.00 • 0.50-1.20 0.50-1.80
OXMT 050705-R-HP (2) 2.70 15.10 1.24 7.00 4.30 • 0.50-2.50 0.12-0.30
• To be used without a seat • For cutting speed recommendations, see pages 542-547
(1) For high feed milling
(2) 45° edges for austenitic stainless steel and high temperature alloys
For tools, see pages: FF SOF (310) • SOE45 8/16 (38) • SOF45 (222)

-FF -HP

OECR
Octagonal Milling Inserts IC
with Positive Rake and
Sharp Cutting Edges
45° APMX
BS RE S

Dimensions Tough 1 Hard Recommended
Machining Data

fz
ap
Designation IC APMX BS RE S IC28 IC830 IC928 IC808 (mm) (mm/t)
OECR 060405AER 14.45 3.70 1.60 0.50 4.90 • 1.00-3.70 0.12-0.20
OECR 060405AER-P (1) 14.45 3.70 1.60 0.50 4.90 • • • 1.00-3.70 0.08-0.20
• For cutting speed recommendations, see pages 542-547
(1) Polished rake used for aluminum and titanium
For tools, see pages: HOE-R06 (218) • HOF-R06 (218)
