MILLING INSERTS S845 SNMU/SNHU 1806 Dimensions IC BS L RE APMX Tough 1 Hard Machining Data
S
Square Inserts with 8 Helical
Right-Hand Cutting Edges

Recommended

fz
ap
BS
IC
Designation
(mm)
(mm/t)
RE
S
3.50
S845 SNMU 1806ANR
8.00
1.50-8.00
18.80
2.40
8.00
7.00
3.50
1.00
0.15-0.30
S845 SNMU 1806ANR-MM
•
2.30
0.20-0.40
S845 SNMU 1806ANR-RM 18.80 2.40 CW 1.00 APMX 7.00 • IC330 • IC845 • IC830 • IC5400 • IC808 • IC810 • IC5100 1.50-8.00 0.15-0.30
1.50-8.00
1.60
8.00
3.50
7.00
18.80
S845 SNHU 1806ANR 18.80 2.40 3.50 1.00 8.00 7.00 • • 1.50-8.00 0.15-0.30
S845 SNHU 1806ANR-MM 18.80 2.40 3.50 1.00 8.00 7.00 • 1.50-8.00 0.15-0.30
• For cutting speed recommendations, see pages 542-547
For tools, see pages: SOF45-R18 (229)

S845 SNHU 1806AN-N-W IC s
Wiper Insert with 2 R.H. and
2 L.H. Cutting Edges
APMX
BS RE
Dimensions Recommended Machining Data
IC810 ap fz
Designation IC S BS APMX (mm) (mm/t)
S845 SNHU 1806AN-N-W 18.80 7.00 10.00 8.00 • 0.50-2.00 0.10-0.25
For tools, see pages: SOF45-R18 (229)

S

S845 SNMU 2608 IC
Heavy Duty Thick Square Inserts
with 8 Helical Right-Hand
Cutting Edges
APMX
RE BS
Recommended
Dimensions Tough 1 Hard Machining Data

IC830 IC5400 IC808 IC810 ap fz
Designation IC BS RE APMX S (mm) (mm/t)
S845 SNMU 2608ANR-HL 26.30 2.60 1.60 11.00 10.90 • 2.00-11.00 0.25-0.40
S845 SNMU 2608ANR-RM 26.30 2.60 1.60 11.00 10.90 • • • 2.00-11.00 0.25-0.40
• For cutting speed recommendations, see pages 542-547
For tools, see pages: SOF45-26 (228) • SOF45WG-R26 (228)
