MILLING INSERTS FFX4 XNMU-08 Dimensions RE W1 Tough 1 Hard Recommended Machining Data
S1

"Bone Shaped" Inserts
Rd°
INSL
with 4 Cutting Edges for
Fast Feed Milling

fz
ap
IC882
IC830
IC808
S1
INSL
Designation
RE
(mm)
(mm/t)
W1
•
•
•
7.80
17.90
2.00
15.60
FFX4 XNMU 080620HP
•
•
•
17.90
7.80
0.40-1.20
0.20-2.00
2.00
15.60
FFX4 XNMU 080620T
• For side plunging, the initial cutting feed is 0.1 mm/t • T-for steel, ferritic and martensitic stainless steel, cast iron and hardened steel IC810 0.20-2.00 0.20-0.60
• HP-for austenitic stainless steel and high temperature alloys
For tools, see pages: FFX4 FD-08 (296)
Averaged Cutting Data for FFX4 Fast Feed Cutters Size 08
Workpiece material Cutting
ISO class ISCAR Typical representstive D.O.C. speed Feed
DIN/ISO mat. Hardness AISI/SAE/ Insert Carbide ap vc fz
513 Description group* HB ASTM DIN W.-Nr. type grade [mm] [m/min] [mm/tooth] Coolant
Non-alloy steel 1-5 130-180 1020 1.0402 IC808 150-180 0.40-1.20 Dry
IC830 150-180 0.40-1.20 Dry/Wet
6-8 260-300 4340 1.6582 IC808 150-180 0.40-1.20 Dry/Wet
120-180
Dry/Wet
0.40-1.10
IC830
Low alloy steel HRC IC808 130-180 0.40-1.10 Dry
P 9 35-42** 3135 1.5710 T IC830 0.50-2.0 120-160 0.40-1.00 Dry/Wet
Dry
High alloy steel 10-11 200-220 H13 1.2344 IC808 120-170 0.40-0.80 Dry/Wet
100-150
0.40-0.90
IC830
Ferritic/martensitic 12-13 200 420 1.4021 IC808 110-160 0.40-0.80 Dry
stainless steel IC830 100-150 0.40-0.90 Dry/Wet
Austenitic IC830 70-130 0.20-0.80
M 14 200 304L 1.4306 HP IC808 0.50-2.0 100-160 0.20-0.80 Wet
stainless steel IC882 80-140 0.20-0.80
K Grey cast iron 15-16 250 Class 40 0.6025 (GG25) T IC810 0.50-2.0 150-220 0.40-1.20 Dry
Nodular cast iron 17-18 200 Class 65-45-12 0.7050 (GGG50) IC810 120-200 0.40-1.20
IC882 40-60 0.20-0.70
31-32 220 330 1.4864 IC808 40-80 0.20-0.70
IC830 40-75 0.20-0.70
High temperature IC882 20-30 0.20-0.70
S 33-35 340 Inconel 718 2.4668 HP IC808 0.50-2.0 25-40 0.20-0.70 Wet
alloys IC830 25-35 0.20-0.70
IC882 30-50 0.20-0.70
36-37 30-32 AMS R56400 (Ti6AI4V ELI) IC808 40-60 0.20-0.70
IC830 35-55 0.20-0.70
H Hardened steel 38 HRC 45-49 HARDOX 450 plate T IC808 0.50-2.0 50-75 0.20-0.50 Dry
* ISCAR material group in accordance with VDI 3323 standard
** Quenched and tempered
For machining in unstable conditions, the recommended cutting data should be reduced by 20-30%

H1200 HXCU 0606 IC
Double-Sided Hexagonal
Inserts with 12 Cutting Edges
RE APMX
L
BS S
Recommended
Dimensions Tough 1 Hard
Machining Data
IC845 IC840 IC830 IC5500 IC808 IC810 ap fz
Designation APMX L BS RE IC S (mm) (mm/t)
H1200 HXCU 0606-HPR (1) 3.00 6.43 1.06 1.60 14.88 7.15 • • 0.20-3.00 0.08-0.40
H1200 HXCU 0606-TR (2) 3.00 6.43 1.06 1.60 14.88 7.15 • • • • • 0.20-3.00 0.25-0.65
• For cutting speed recommendations, see pages 542-547
(1) HPR - for stainless steel and high temperature alloys
(2) TR - for steel and cast iron
For tools, see pages: MF FHX-R06 (308)
TR HPR
