BT MAS-403 BT-FC-SRKIN CRKS SS THID LBX ADJRGA DCONWS BTED BD A 0.005 A AT3 Taper 50-52 HRc
LSCWS
M6
Thermal Shrink Chucks with
G2.5
BT 40=25,000RPM
BT MAS-403 Face Contact
BT 50=20,000 RPM
U<1.0 gmm
AD Tapered Shanks
4.5°
LB
LPR
BD
LB
Designation
BT40 FC SRKIN 6X90
21.00
M5
M16
40
0
6.00
36.0
64.0
11.00
90.00
1.16
BT40 FC SRKIN 8X90 SS DCONWS BTED 27.00 LPR LBX 38.00 ADJRGA LSCWS THID CRKS CDI (1) kg
0
M16
38.00
64.0
36.0
11.00
90.00
8.00
40
27.00
21.00
1.14
M6
BT40 FC SRKIN10X90 40 10.00 24.00 32.00 90.00 64.0 50.80 11.00 42.0 M8 M16 0 1.29
BT40 FC SRKIN12X90 40 12.00 24.00 32.00 90.00 64.0 50.80 11.00 47.0 M10 M16 0 1.28
BT40 FC SRKIN14X90 40 14.00 27.00 34.00 90.00 64.0 44.50 11.00 47.0 M10 M16 0 1.32
BT40 FC SRKIN16X90 40 16.00 27.00 34.00 90.00 64.0 44.50 11.00 50.0 M12 M16 0 1.31
BT40 FC SRKIN18X90 40 18.00 33.00 42.00 90.00 64.0 57.20 11.00 50.0 M12 M16 0 3.00
BT40 FC SRKIN20X90 40 20.00 33.00 42.00 90.00 64.0 57.20 11.00 52.0 M16 M16 0 1.43
BT40 FC SRKIN25X110 40 25.00 44.00 53.00 110.00 84.0 57.20 11.00 58.0 M16 M16 0 2.03
BT50 FC SRKIN 6X100 50 6.00 21.00 27.00 100.00 63.5 38.00 11.00 36.0 M6 M24 0 13.99
BT50 FC SRKIN 8X100 50 8.00 21.00 27.00 100.00 63.5 38.00 11.00 36.0 M5 M24 0 3.86
BT50 FC SRKIN10X100 50 10.00 24.00 32.00 100.00 63.5 50.80 11.00 42.0 M8 M24 0 10.00
BT50 FC SRKIN12X100 50 12.00 24.00 32.00 100.00 63.5 50.80 11.00 47.0 M10 M24 0 3.73
BT50 FC SRKIN14X100 50 14.00 27.00 34.00 100.00 63.5 44.50 11.00 47.0 M10 M24 0 10.00
BT50 FC SRKIN16X100 50 16.00 27.00 34.00 100.00 63.5 44.50 11.00 50.0 M12 M24 0 3.76
BT50 FC SRKIN20X100 50 20.00 33.00 42.00 100.00 63.5 57.20 11.00 52.0 M16 M24 0 3.87
BT50 FC SRKIN25X120 50 25.00 44.00 53.00 120.00 83.5 57.20 11.00 58.0 M16 M24 0 4.47
BT50 FC SRKIN32X120 50 32.00 44.00 53.00 120.00 83.5 57.20 11.50 62.0 M16 M24 0 10.00
• Use only inductive heating device for SRKIN holders
(1) 1 - Hole for data chip, 0 - Without hole for data chip
BT-FC Face Contact Taper
Face Contact Standard
Spindle Spindle
712-713 689-691 694-695
Face Contact Standard
Holder Holder

Spare Parts
Designation
BT40 FC SRKIN 6X90 PRESET M5X18B
BT40 FC SRKIN 8X90 PRESET M6X20B
BT40 FC SRKIN10X90 PRESET M8X20B
BT40 FC SRKIN12X90 PRESET M10X18B
BT40 FC SRKIN14X90 PRESET M10X18B
BT40 FC SRKIN16X90 PRESET M12X18B
BT40 FC SRKIN18X90 PRESET M12X18B
BT40 FC SRKIN20X90 PRESET M16X20B
BT40 FC SRKIN25X110 PRESET M16X25B
BT50 FC SRKIN 6X100 PRESET M5X18B
BT50 FC SRKIN 8X100 PRESET M6X20B
BT50 FC SRKIN10X100 PRESET M8X20B
BT50 FC SRKIN12X100 PRESET M10X18B
BT50 FC SRKIN14X100 PRESET M10X18B
BT50 FC SRKIN16X100 PRESET M12X18B
BT50 FC SRKIN20X100 PRESET M16X20B
BT50 FC SRKIN25X120 PRESET M16X25B
BT50 FC SRKIN32X120 PRESET M16X25B
